Product Detailed Parameters
- Description：W-CDMA UPCONVERTER
- Series：-
- Mfr：Analog Devices Inc./Maxim Integrated
- Package：Bulk
- Function：Upconverter
- Frequency：2.27GHz ~ 2.58GHz
- RF Type：PCS, TD-SCDMA, UMTS
- Secondary Attributes：2.7V ~ 3V Supply
- Mounting Type：Surface Mount
- Package / Case：12-WFBGA, CSPBGA
- Supplier Device Package：12-UCSP
- Grade：-
- Qualification：-
Download product information
Overview
The MAX2383EBC-T is a W-CDMA upconverter and power amplifier driver with integrated power control, manufactured by Analog Devices Inc. (Maxim Integrated). It operates within a frequency range of 2.27GHz to 2.58GHz. The device supports standard functionality for RF and wireless applications, combining upconversion and PA driving capabilities in a single component.
Feature Summary
- Integrates W-CDMA upconverter and power amplifier driver functions
- Includes built-in power control mechanisms
- Designed for specific RF and wireless communication standards
Applications
- W-CDMA mobile phone systems
- RF front-end modules for wireless handsets
- Base station transmitter chains
Procurement Notes
Verify the manufacturer designation as Analog Devices Inc. or Maxim Integrated, as both names are associated with this part history. Confirm the package type matches UCSP-12 specifications. Ensure the revision level aligns with current production requirements. Check RoHS compliance status if environmental regulations apply to your deployment. Validate that the suffix -T indicates tape-and-reel packaging if required for assembly processes.
Selection Notes
Select this component when designing W-CDMA transmitters requiring integrated upconversion and PA driving. It simplifies board space by combining multiple RF stages. Consider its specific frequency range of 2.27GHz to 2.58GHz for band compatibility. Evaluate power control integration needs against external circuit complexity. Verify interface requirements with the host processor for power management commands.
Part Context
This device belongs to the Maxim Integrated RF and wireless IC portfolio, specifically targeting cellular infrastructure and mobile terminals. It represents a solution for reducing component count in W-CDMA designs. The integration of upconversion and PA driver reduces interconnect losses and improves overall system efficiency compared to discrete solutions.
Replacement Considerations
Public confirmed substitute part numbers are not available in the provided documentation. Consult official distributor databases for cross-reference lists.
