MAX6023EBT41+

Overview

The MAX6023EBT41+ is a precision series voltage reference manufactured by Analog Devices Inc./Maxim Integrated. It provides a fixed output voltage of 4.096 V with an initial accuracy of 0.24%. The device features a temperature coefficient of 30 PPM/C and supports an input voltage range up to 12.6 V. It operates within a temperature range of -40°C to +85°C and is housed in a UCSP-5 surface-mount package.

Feature Summary

• Delivers high-precision voltage regulation with tight initial accuracy tolerances for sensitive measurement applications.
• Maintains stable performance across wide temperature variations through low temperature coefficient design.
• Utilizes compact UCSP packaging to minimize board space requirements while supporting surface-mount assembly.

Applications

• Precision data acquisition systems requiring stable reference voltages
• High-resolution analog-to-digital converter (ADC) biasing
• Portable instrumentation powered by single supply sources

Procurement Notes

Verify the specific suffix EB and output code 41 against official datasheets to confirm the 4.096V output variant. Ensure the UCSP-5 package matches your PCB footprint. Confirm RoHS compliance status and check for obsolescence notices from Analog Devices before finalizing procurement plans.

Selection Notes

Select this component when a fixed 4.096V reference is required with 0.24% accuracy. Consider the UCSP-5 package size constraints and the 12.6V maximum input voltage limit. Evaluate thermal management needs within the -40°C to +85°C operating range for your specific application environment.

Part Context

This part belongs to the MAX6023 series of low-power, low-dropout voltage references. It is designed for applications demanding high precision and stability in small form factors. The series is commonly used in battery-powered devices and industrial sensors where power efficiency and accuracy are critical.

Replacement Considerations

Check for direct pin-compatible substitutes within the MAX6023 family with different output voltages or accuracies. Verify if alternative packages like SOT-23-5 offer similar electrical characteristics if board space allows for redesign.
