MAX6023EBT50+T

Overview

The MAX6023EBT50+T is a precision, low-power, low-dropout voltage reference IC manufactured by Analog Devices Inc./Maxim Integrated. It provides a fixed output voltage of 5 V with an initial accuracy of 0.24% and a temperature coefficient of 30 PPM/C. The device operates within an input voltage range up to 12.6 V and functions across a temperature range of -40°C to +85°C. It is housed in a compact UCSP-5 surface-mount package.

Feature Summary

• Precision series voltage reference design ensuring stable output performance
• Low-power architecture optimized for battery-operated applications
• Low-dropout regulator capability for efficient operation near supply limits

Applications

• Portable instrumentation systems requiring precise voltage standards
• Battery-powered measurement devices
• Data acquisition systems with high-resolution ADCs

Procurement Notes

Verify the specific suffix against official documentation to confirm the exact output voltage and tolerance grade. Confirm package availability and RoHS compliance status through authorized distributors. Ensure the ordering part number matches the required electrical specifications for your design.

Selection Notes

Select this component when a fixed 5 V reference with high initial accuracy is required in a minimal footprint. Consider the 30 PPM/C temperature coefficient for thermal stability needs. Evaluate the UCSP-5 package constraints for PCB layout and thermal management requirements.

Part Context

This part belongs to the MAX6023 series of precision voltage references from Maxim Integrated. The series offers various output voltages and accuracy grades in compact packages suitable for space-constrained designs.
