MBRBFL20100CT-TP

$2.09

Description：DIODE ARR SCHOT 100V 10A TO263AC
Series：-

SKU:f12334ee752b Category: Diode Arrays Brand: MCC (Micro Commercial Components)

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

MBRBFL20100CT-TP is listed in the Diode Arrays range at ChipApex. The manufacturer field lists MCC (Micro Commercial Components). Its product description is DIODE ARR SCHOT 100V 10A TO263AC. Review the specifications below when checking this part for your BOM.

Diode Arrays specifications for MBRBFL20100CT-TP

Description：DIODE ARR SCHOT 100V 10A TO263AC
Series：-
Mfr：MCC (Micro Commercial Components)
Package：Tape & Reel (TR),Cut Tape (CT)
Diode Configuration：1 Pair Common Cathode
Technology：Schottky
Voltage - DC Reverse (Vr) (Max)：100 V
Current - Average Rectified (Io) (per Diode)：10A
Voltage - Forward (Vf) (Max) @ If：750 mV @ 10 A
Speed：Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr)：-
Current - Reverse Leakage @ Vr：20 µA @ 100 V
Operating Temperature - Junction：-55°C ~ 150°C
Mounting Type：Surface Mount
Package / Case：TO-263-3, D2PAK (2 Leads + Tab), TO-263AB
Supplier Device Package：TO-263AC
Grade：-
Qualification：-

Diode Arrays datasheet and documents for MBRBFL20100CT-TP

MBRBFL20100CT-TP

Diode Arrays Overview

The MBRBFL20100CT-TP is a dual common cathode Schottky barrier rectifier manufactured by Micro Commercial Components. It features a TO-263AC (D2PAK) surface-mount package with four terminals. The device supports an average forward current of 20 Amperes per diode and a peak repetitive reverse voltage of 100 Volts. Electrical characteristics include a maximum forward voltage drop of 0.75 V at 10 A and 25°C, and a maximum reverse leakage current of 20 mA at 100 V and 125°C. Thermal resistance from junction to case is typically 2°C/W.

Diode Arrays Feature Summary

Halogen-free construction compliant with RoHS directives
Low forward voltage drop for reduced power losses
Very low profile design with typical height of 1.7 mm
Epoxy material meets UL 94 V-0 flammability rating

Diode Arrays Applications

Low voltage high frequency inverters
Free wheeling applications
Polarity protection circuits

Diode Arrays Procurement Notes

Verify the component authenticity by checking the manufacturer's marking against official datasheet specifications. Purchase only from authorized distributors to ensure traceability and quality standards. Confirm the specific tape and reel quantity matches project requirements before ordering.

Diode Arrays Selection Notes

Select this component for applications requiring high surge capability and low switching losses in compact designs. Ensure thermal management accounts for the junction-to-case resistance when operating near maximum temperature limits. Verify that the 100V reverse voltage rating exceeds the circuit's peak inverse voltage.

Diode Arrays Part Context

This part belongs to the MBRBFL series of low VF Schottky Barrier Rectifiers. It utilizes silicon technology to provide efficient rectification in surface-mount configurations. The dual common cathode arrangement allows for use in bridge or full-wave rectifier topologies within a single package.

Diode Arrays Replacement Considerations

Cross-reference with other MCC MBRBFL series variants for different current ratings. Verify pinout compatibility with existing PCB footprints when substituting similar packages from other manufacturers.
