MDD255-22N1

$141.09

Description：DIODE MODULE GP 2200V 270A Y1-CU
Series：-

SKU:abc26590fdf9 Category: Diode Arrays Brand: IXYS

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：DIODE MODULE GP 2200V 270A Y1-CU
Series：-
Mfr：IXYS
Package：Box
Diode Configuration：1 Pair Series Connection
Technology：Standard
Voltage - DC Reverse (Vr) (Max)：2200 V
Current - Average Rectified (Io) (per Diode)：270A
Voltage - Forward (Vf) (Max) @ If：1.4 V @ 600 A
Speed：Standard Recovery >500ns, > 200mA (Io)
Reverse Recovery Time (trr)：-
Current - Reverse Leakage @ Vr：30 mA @ 2200 V
Operating Temperature - Junction：-40°C ~ 150°C
Mounting Type：Chassis Mount
Package / Case：Y1-CU
Supplier Device Package：Y1-CU
Grade：-
Qualification：-

Download product information

MDD255-22N1

Overview

The MDD255-22N1 is a high-power silicon rectifier diode module from the IXYS MDD255 series. It features a peak repetitive reverse voltage of 2200V and a maximum continuous forward current of 255A. The device utilizes a Y2-DCB package with screw mount installation, designed for robust thermal management in industrial applications. Key electrical parameters include a maximum forward voltage drop of 1.4V at rated current and a peak non-repetitive forward surge current capability of 10.6kA. Operating temperatures range from -40°C to +150°C junction temperature.

Feature Summary

High voltage blocking capability suitable for demanding power conversion environments
Robust mechanical construction with screw mount design for secure panel integration
Optimized thermal performance through direct copper bond substrate technology

Applications

Industrial motor drives and variable frequency drives
High voltage DC power supply rectification
Welding equipment power stages

Procurement Notes

Verify component authenticity against manufacturer datasheets prior to implementation. Confirm package dimensions and mounting hole patterns match system requirements. Ensure thermal interface materials are compatible with the specified operating temperature range. Check for end-of-life notifications or discontinuance notices that may affect long-term availability.

Selection Notes

Select this module when system requirements demand high voltage isolation combined with substantial continuous current handling. Evaluate thermal resistance characteristics against available cooling solutions. Compare forward voltage specifications against efficiency targets. Verify surge current ratings align with potential fault conditions within the circuit topology.

Part Context

This component belongs to the MDD255 series of high-current diode modules manufactured by IXYS. The series is engineered for heavy-duty industrial applications requiring reliable rectification under harsh electrical and thermal conditions. These modules represent a specialized segment of power electronics components focused on durability and high-performance switching capabilities.
