MPC603RRX200LC

Overview

The MPC603RRX200LC is a PowerPC 603e RISC microprocessor manufactured by Motorola, operating at a CPU frequency of 200 MHz. It utilizes a CBGA package with a 255 mm footprint and Revision 2.1 process mask code PPC3.0 (2H93J). The device operates within a junction temperature range of 0 to 105 °C and requires a Vdd supply voltage of 2.5 V ± 5%. This specific part number represents manufacturing improvements over previous revisions without functional differences.

Feature Summary

• PowerPC 603e architecture implementation
• Revision 2.1 manufacturing improvements
• CBGA package configuration

Applications

• Embedded systems requiring PowerPC 603e processing
• Industrial control applications
• Communication equipment

Procurement Notes

Verify the exact revision level and mask code when sourcing this component. Confirm that the supplier provides documentation acknowledging the Revision 2.1 manufacturing updates. Ensure compatibility with existing system designs regarding the specified thermal and electrical operating conditions.

Selection Notes

Select this processor for applications necessitating the PowerPC 603e core at 200 MHz. Consider the CBGA package constraints during PCB layout. Review the documented errata regarding cache coherency and bus reservation behaviors to ensure software or hardware mitigation strategies are in place.

Part Context

This component belongs to the PowerPC 603e family, specifically designated as the 'Goldeneye' variant. It is functionally equivalent to the PID7v-603e (Valiant) microprocessor Revision 2.1. The part number structure indicates a 200 MHz clock speed and standard commercial temperature range operation.

Replacement Considerations

MPC603RRX166LC, MPC603RRX233LC, MPC603RRX266LC, MPC603RRX300LC, MPE603RRX200LC, MPC603RRX200TC.
