MPC8308VMADD

Description：IC MPU MPC83XX 266MHZ 473MAPBGA
Series：MPC83xx
Mfr：NXP USA Inc.
Package：Tray

SKU:00d07247f9e0 Category: Microprocessors Brand: NXP USA Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：IC MPU MPC83XX 266MHZ 473MAPBGA
Series：MPC83xx
Mfr：NXP USA Inc.
Package：Tray
Core Processor：PowerPC e300c3
Number of Cores/Bus Width：1 Core, 32-Bit
Speed：266MHz
Co-Processors/DSP：-
RAM Controllers：DDR2
Graphics Acceleration：No
Display & Interface Controllers：-
Ethernet：10/100/1000Mbps (3)
SATA：-
USB：USB 2.0 (1)
Voltage - I/O：1.8V, 2.5V, 3.3V
Operating Temperature：0°C ~ 105°C (TA)
Security Features：-
Mounting Type：Surface Mount
Package / Case：473-LFBGA
Supplier Device Package：473-MAPBGA (19x19)
Additional Interfaces：DUART, HSSI, I2C, MMC/SD/SDIO, SPI

Download product information

MPC8308VMADD

Overview

The MPC8308VMADD is a PowerQUICC II Pro processor featuring an e300c3 core operating up to 400 MHz with 16 KB instruction and data caches. It integrates dual three-speed Ethernet MACs, a DDR2 controller supporting 266 MHz transfers, one PCI Express interface, USB 2.0, eSDHC, IEEE 1588v2 time synchronization, and multiple serial interfaces including I2C, SPI, and DUART. The device utilizes a 473-pin MAPBGA package measuring 19 mm x 19 mm.

Feature Summary

Integrates an e300c3 core based on Power Architecture technology for high-performance processing.
Includes dual three-speed Ethernet controllers supporting MII and RGMII modes.
Features integrated IEEE 1588 version 2 time synchronization capabilities.
Provides a comprehensive set of peripherals including PCI Express, USB 2.0, and DDR2 memory control.

Applications

Smart grid home energy gateways
Wireless LAN access points
Industrial network switches

Procurement Notes

Verify the specific suffix 'VMADD' against official NXP documentation to confirm voltage levels, temperature range, and package details. Ensure compatibility with existing board designs regarding power sequencing and signal integrity requirements defined in the hardware specification.

Selection Notes

Select this component for applications requiring low-power communication processing with integrated time synchronization. Evaluate system requirements against the available peripheral count and interface speeds to ensure adequate bandwidth for target network protocols.

Part Context

This part belongs to the PowerQUICC II Pro family, designed for cost-effective and low-power network applications. It extends previous generations by offering higher CPU performance and faster interfaces within a compact package size suitable for embedded systems.

Replacement Considerations

Consult official substitution lists for pin-compatible or functionally equivalent processors within the PowerQUICC series. Verify software compatibility and peripheral mapping before transitioning to alternative models.
