MPG06MHE3_A/100

Single Diodes Overview

The MPG06MHE3_A/100 is a general-purpose rectifier diode manufactured by Vishay General Semiconductor - Diodes Division. It features a maximum repetitive peak reverse voltage of 1000 V and an average forward rectified current of 1 A. The device utilizes a through-hole mounting type within the MPG06 plastic case. Key electrical characteristics include a maximum reverse leakage current of 5 µA at 1000 V and a capacitance of 10 pF at 4 V and 1 MHz.

Single Diodes Feature Summary

• Designed for general-purpose rectification applications
• Utilizes a miniature plastic encapsulated package
• Features isolated case connection

Single Diodes Applications

• Free wheeling diode circuits
• General purpose rectification in power supplies
• DC-AC conversion stages

Single Diodes Procurement Notes

Verify the specific suffix to confirm the reel quantity, as indicated by the /100 designation. Ensure the component meets RoHS requirements if applicable, noting that some variants may have different compliance statuses. Cross-reference the manufacturer part number with official Vishay documentation to confirm availability and exact packaging specifications before procurement.

Single Diodes Selection Notes

Select this component when high reverse voltage capability is required alongside moderate current handling. The MPG06 package offers a compact solution for through-hole designs. Consider the reverse leakage and capacitance values for high-frequency or sensitive circuit applications. Ensure the thermal management aligns with the device's junction temperature ratings during operation.

Single Diodes Part Context

This part belongs to the MPG06 series of silicon rectifier diodes from Vishay. These components are characterized by their robust construction and suitability for various industrial and consumer electronics applications. The series provides reliable performance in standard rectification roles, offering a balance between voltage rating and current capacity in a small form factor.

Single Diodes Replacement Considerations

Check for direct equivalents such as the MPG06M variant. Verify pin compatibility and electrical parameters like Vf and trr. Ensure the replacement maintains the same package style and mounting requirements.
