MPXH6101AC6T1

Pressure Sensors Transducers Overview

The MPXH6101AC6T1 is an absolute pressure sensor from the MPXH6101A series manufactured by STMicroelectronics. It features a working pressure range of 2.18 PSI to 15.23 PSI (15 kPa to 105 kPa) with a maximum pressure rating of 58.02 PSI (400 kPa). The device provides an analog voltage output ranging from 0.2 V to 5 V, powered by a supply voltage between 4.75 V and 5.5 V. It has an accuracy of ±1.72% and operates within a temperature range of -40°C to 125°C. The component is housed in an 8-SSOP package with鸥翼 termination.

Pressure Sensors Transducers Feature Summary

• Integrated temperature compensation for stable performance across operating conditions
• Absolute pressure measurement capability without reference to ambient atmospheric changes
• Analog voltage output signal compatible with standard interface circuits

Pressure Sensors Transducers Applications

• Board mount pressure sensing systems
• Industrial process control monitoring
• HVAC system pressure detection

Pressure Sensors Transducers Procurement Notes

Verify manufacturer designation as STMicroelectronics despite NXP branding references in some listings. Confirm RoHS3 compliance and MSL level 1 status. Ensure correct part suffix AC6T1 matches required port style and packaging. Cross-reference datasheet specifications against procurement requirements to avoid substitution errors.

Pressure Sensors Transducers Selection Notes

Select this component for applications requiring absolute pressure measurement within the 15 kPa to 105 kPa range. Consider the 8-SSOP surface mount package for PCB integration. Evaluate the ±1.72% accuracy and temperature compensated operation for environmental stability needs. Verify power supply compatibility with the 4.75 V to 5.5 V operating range.

Pressure Sensors Transducers Part Context

This sensor belongs to the MPXH6101A series, designed for board-mounted pressure sensing applications. It utilizes silicon piezoresistive technology integrated into a compact SSOP package. The series offers temperature-compensated outputs suitable for various industrial and consumer electronics environments requiring reliable pressure data acquisition.

Pressure Sensors Transducers Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Consult official manufacturer channels for cross-reference information or equivalent series components.
