MSFC110-16

Overview

The MSFC110-16 is a power module thyristor/diode manufactured by Microsemi Corporation. It features an average on-state current of 110A and a non-repetitive surge current rating of 2250A at 50Hz. The component is designed for high-power applications requiring robust switching capabilities.

Feature Summary

• High current handling capability with 110A average on-state current
• Robust surge protection with 2250A non-repetitive surge rating
• Integrated thyristor and diode configuration in a single module

Applications

• Industrial power conversion systems
• Motor control drives
• High-power rectification circuits

Procurement Notes

Verify the manufacturer source, as Microsemi's power products group has undergone corporate changes. Confirm the specific package type and pinout configuration against the official datasheet to ensure compatibility with existing PCB layouts. Check for any lead-free or RoHS compliance markings if required by your assembly process.

Selection Notes

Select this component when high average current and significant surge tolerance are required in a compact module form factor. Consider the thermal management requirements associated with 110A operation. Ensure the voltage ratings align with the system's peak reverse voltage demands before finalizing the design.

Part Context

This part belongs to Microsemi's power semiconductor portfolio, which includes various discrete components and modules. The company specializes in high-performance analog mixed-signal ICs and power management solutions. This specific module addresses needs for reliable high-current switching in demanding industrial environments.

Replacement Considerations

Publicly confirmed substitute part numbers for the MSFC110-16 are not available in the provided documentation. Engineers should consult Microsemi or authorized distributors for direct equivalents or cross-reference options based on specific electrical and mechanical constraints.
