Product Detailed Parameters
- Description：DIODE ARRAY GP 600V 20A D2PAK
- Series：-
- Mfr：MCC (Micro Commercial Components)
- Package：Bulk
- Diode Configuration：1 Pair Common Cathode
- Technology：Standard
- Voltage - DC Reverse (Vr) (Max)：600 V
- Current - Average Rectified (Io) (per Diode)：20A
- Voltage - Forward (Vf) (Max) @ If：1.6 V @ 10 A
- Speed：Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr)：35 ns
- Current - Reverse Leakage @ Vr：5 µA @ 600 V
- Operating Temperature - Junction：-55°C ~ 150°C
- Mounting Type：Surface Mount
- Package / Case：TO-263-3, D2PAK (2 Leads + Tab), TO-263AB
- Supplier Device Package：D2PAK
- Grade：-
- Qualification：-
Download product information
Overview
The MURSB2060CTA-TP is a fast recovery rectifier diode manufactured by Micro Commercial Components (MCC). It features a dual common cathode configuration housed in a TO-263-3 (D2PAK) surface-mount package. The device supports a continuous forward current of 20 A and withstands a repetitive peak reverse voltage of 600 V. Key electrical characteristics include a maximum non-repetitive surge current of 150 A, a typical reverse leakage current of 5 µA at rated voltage, and a maximum reverse recovery time of 35 ns. The component operates within a junction temperature range of -55°C to +175°C.
Feature Summary
- Dual common cathode architecture for efficient bridge or center-tap applications
- High thermal performance via exposed tab design in D2PAK package
- Fast recovery characteristics suitable for high-frequency switching
- Extended operating junction temperature range up to 175°C
Applications
- High-frequency DC/DC converters
- Free-wheeling rectification in power supplies
- Inductive load protection circuits
- Uninterruptible Power Supply (UPS) systems
Procurement Notes
Verify the specific suffix 'TP' indicates the standard tape and reel packaging format as per MCC documentation. Confirm RoHS compliance status through the official datasheet before integration. Ensure the ordering quantity aligns with the factory pack size of 800 units to avoid partial reel handling issues during assembly.
Selection Notes
Select this component when a dual common cathode configuration is required for space-constrained surface-mount designs. The TO-263-3 package offers superior heat dissipation compared to smaller SMD packages. Consider the 600 V rating for primary-side rectification or secondary-side outputs requiring higher voltage isolation margins.
Part Context
This part belongs to the MURSB series of Super Fast Recovery Rectifiers from Micro Commercial Components. It complements other MCC diodes like the MBRB2060CT-TP, which offers Schottky technology but lower voltage ratings. The MURSB series is designed for applications demanding faster switching speeds than standard recovery diodes while maintaining robust current handling capabilities.
Replacement Considerations
Direct pin-compatible substitutes may include the MURSB2060CT-BP variant, differing primarily in packaging style. Verify that any replacement maintains the 600 V reverse voltage and 20 A current ratings. Check if alternative manufacturers offer equivalent fast recovery diodes in the TO-263-3 package with matching electrical specifications.
