NGCL5030UG1R575G4TRF

Antennas RF Overview

The NGCL5030UG1R575G4TRF is a surface-mount RF antenna manufactured by NIC Components Corp. It supports multiple GNSS frequency bands including GPS L1 at 1575.42 MHz, GLONASS L1 at 1602 MHz, and BeiDou B1 at 1561.098 MHz. The component features a compact 5030 package size with solder termination for direct PCB mounting.

Antennas RF Feature Summary

• Supports multi-constellation GNSS reception including GPS, GLONASS, and BeiDou
• Compact surface-mount design suitable for space-constrained applications

Antennas RF Applications

• GPS navigation modules
• GLONASS positioning systems
• BeiDou receiver integration

Antennas RF Procurement Notes

Verify the specific frequency band requirements against the datasheet specifications before procurement. Confirm that the surface-mount footprint matches the target PCB layout. Ensure compatibility with standard reflow soldering processes to maintain antenna performance integrity during assembly.

Antennas RF Selection Notes

Select this component when multi-band GNSS support is required in a minimal form factor. Evaluate the typical gain values for each supported frequency to ensure adequate signal reception for the intended application environment. Consider the mechanical stability provided by the chip-style construction.

Antennas RF Part Context

This part belongs to the NGCL series of ceramic chip antennas from NIC Components Corp. These components are designed for global navigation satellite system applications, offering a balance between performance and physical size for modern electronic devices requiring location services.
