NJECBLJHNY-10.000000

Oscillators Overview

The Taitien NJECBLJHNY-10.000000 is a 10 MHz Oven-Controlled Crystal Oscillator (OCXO) featuring a CMOS output interface and a 3.3V supply voltage. It utilizes a metal-ceramic sealed structure within a compact 7-SMD, No Lead package measuring 5.0 x 3.2 x 0.9 mm. The device operates across a temperature range of -40°C to 85°C with a frequency stability of ±10 ppm and an absolute pull range of ±0.5 ppm. Maximum supply current is 1A.

Oscillators Feature Summary

• Metal-ceramic sealed construction for structural reliability
• Oven-controlled design ensuring high frequency stability
• Compact surface-mount form factor suitable for space-constrained layouts

Oscillators Applications

• Wireless communication systems
• Industrial control motherboards
• IoT gateways
• Consumer electronics requiring precise timing

Oscillators Procurement Notes

Verify the specific part number NJECBLJHNY-10.000000 against official Taitien documentation to confirm electrical parameters and mechanical dimensions. Ensure compatibility with 3.3V CMOS logic levels and check RoHS compliance status prior to integration. Confirm that the 7-SMD no-lead package matches the target PCB footprint and soldering profile requirements.

Oscillators Selection Notes

Select this component when high stability is required in harsh environments due to its OCXO architecture. The metal-ceramic seal provides robustness compared to standard packages. Consider the 1A maximum current draw for power budget calculations. The wide operating temperature range supports deployment in industrial settings without additional thermal management.

Oscillators Part Context

This oscillator belongs to Taitien’s NJ series of frequency control products. Taitien manufactures a broad range of crystal devices including TCXOs, VCXOs, and atomic clocks. This specific model represents their oven-controlled solution designed for applications demanding superior phase noise and long-term stability compared to standard crystal oscillators.

Oscillators Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided source data. Cross-referencing requires matching OCXO specifications, package dimensions, and output types through official manufacturer substitution guides.
