NPI-19A-030G2 is listed in the Pressure Sensors Transducers range at ChipApex. The manufacturer field lists Amphenol Advanced Sensors (NovaSensor). Its product description is SENSOR 30PSIG 14BIT. Review the specifications below when checking this part for your BOM.
Pressure Sensors Transducers specifications for NPI-19A-030G2
- Description：SENSOR 30PSIG 14BIT
- Series：NPI-19
- Mfr：Amphenol Advanced Sensors (NovaSensor)
- Package：Tray
- Applications：Industrial Automation
- Pressure Type：Gauge
- Operating Pressure：30PSI (206.84kPa)
- Output Type：I2C
- Output：14 b
- Accuracy：±1%
- Voltage - Supply：2.5V ~ 5.5V
- Port Size：-
- Port Style：No Port
- Features：Temperature Compensated
- Termination Style：Wire Leads
- Maximum Pressure：60PSI (413.69kPa)
- Operating Temperature：-40°C ~ 125°C
- Mounting Type：-
- Package / Case：Cylinder
- Supplier Device Package：-
Pressure Sensors Transducers datasheet and documents for NPI-19A-030G2
Pressure Sensors Transducers Overview
The NPI-19A-030G2 is a digital I²C pressure sensor from the Amphenol NovaSensor NPI-19 series. It features a gauge pressure range of 30 PSI (206.84 kPa) with a maximum pressure rating of 60 PSI (413.69 kPa). The device provides a 14-bit resolution output via an I²C interface. It operates within a supply voltage range of 2.5V to 5.5V and supports a wide operating temperature range from -40°C to +125°C. The sensor utilizes a cylindrical package and includes a 1/8 inch NPT threaded port for media connection.
Pressure Sensors Transducers Feature Summary
- Digital I²C interface for direct microcontroller integration
- Media-isolated design suitable for liquids and gases
- Integrated temperature compensation for accuracy stability
Pressure Sensors Transducers Applications
- Industrial automation systems
- HVAC monitoring
- Fluid power control
Pressure Sensors Transducers Procurement Notes
Verify the specific suffix codes against the manufacturer's official datasheet to confirm exact pressure type, port configuration, and electrical specifications. Ensure compatibility with system voltage levels and I²C bus requirements before integration. Cross-reference part numbers with authorized distributors to obtain current availability and technical documentation.
Pressure Sensors Transducers Selection Notes
Select this component when a ruggedized digital pressure sensor with I²C connectivity is required for harsh environments. The NPI-19 series offers high accuracy and a wide temperature range. Consider the 30 PSI gauge range and 1/8 NPT port size relative to system pressure limits and plumbing constraints.
Pressure Sensors Transducers Part Context
This part belongs to the NPI-19 series of media-isolated digital pressure sensors by Amphenol Advanced Sensors. The series is designed for industrial applications requiring reliable performance in demanding conditions. The NPI-19A variant specifically denotes the absolute or gauge pressure configuration within the broader product family.
Pressure Sensors Transducers Replacement Considerations
Check for direct substitutes within the NPI-19 series with different pressure ranges or port types. Verify pinout and software compatibility if replacing with other digital pressure sensors.
