NPI-19A-050G2 is listed in the Pressure Sensors Transducers range at ChipApex. The manufacturer field lists Amphenol Advanced Sensors (NovaSensor). Its product description is SENSOR 50PSIG 14BIT. Review the specifications below when checking this part for your BOM.
Pressure Sensors Transducers specifications for NPI-19A-050G2
- Description：SENSOR 50PSIG 14BIT
- Series：NPI-19
- Mfr：Amphenol Advanced Sensors (NovaSensor)
- Package：Tray
- Applications：Industrial Automation
- Pressure Type：Gauge
- Operating Pressure：50PSI (344.74kPa)
- Output Type：I2C
- Output：14 b
- Accuracy：±1%
- Voltage - Supply：2.5V ~ 5.5V
- Port Size：-
- Port Style：No Port
- Features：Temperature Compensated
- Termination Style：Wire Leads
- Maximum Pressure：100PSI (689.48kPa)
- Operating Temperature：-40°C ~ 125°C
- Mounting Type：-
- Package / Case：Cylinder
- Supplier Device Package：-
Pressure Sensors Transducers datasheet and documents for NPI-19A-050G2
Pressure Sensors Transducers Overview
The NPI-19A-050G2 is a digital I²C pressure sensor from the NPI-19 series by Amphenol Advanced Sensors. It features a cylindrical package with wire leads and no ports. The device measures gauge pressure up to 50 PSI (344.74 kPa) with a maximum pressure rating of 100 PSI (689.48 kPa). It offers a 14-bit resolution output and ±1% accuracy. Operating voltage ranges from 2.5V to 5.5V, and it functions within a temperature range of -40°C to 125°C.
Pressure Sensors Transducers Feature Summary
- Digital I²C interface for direct microcontroller connectivity
- Temperature compensated for stable performance across operating ranges
- Robust cylindrical stainless steel construction suitable for harsh environments
Pressure Sensors Transducers Applications
- Industrial automation systems
- HVAC monitoring
- Medical equipment
- Fluid power control
Pressure Sensors Transducers Procurement Notes
Verify the specific suffix G2 confirms the gauge pressure type and I²C digital output configuration. Ensure the cylindrical package style matches the system integration requirements. Confirm that the 50 PSI working pressure range aligns with the application's operational limits before finalizing procurement.
Pressure Sensors Transducers Selection Notes
Select this model for applications requiring a compact, digitally interfaced pressure sensor with high accuracy. Consider the NPI-19 series if media isolation or different port styles are needed. Verify supply voltage compatibility with the host system's logic levels.
Pressure Sensors Transducers Part Context
This component belongs to the NPI-19 family of industrial pressure sensors designed for harsh environments. The series includes various pressure ranges and output types, providing standardized solutions for demanding measurement tasks in industrial and commercial sectors.
Pressure Sensors Transducers Replacement Considerations
Check datasheets for alternative part numbers within the NPI-19 series that offer compatible pinouts and electrical characteristics. Ensure any substitute maintains the same pressure rating and digital interface protocol.
