NPI-19A-100G2

Pressure Sensors Transducers Overview

The NPI-19A-100G2 is a digital absolute pressure sensor from the NPI-19 series manufactured by Amphenol Advanced Sensors. It features a cylindrical package with wire leads and an I2C output interface. The device operates within a supply voltage range of 2.5V to 5.5V and provides a 14-bit resolution. It is designed for harsh environments, offering temperature compensation and media isolation capabilities. The sensor supports a maximum operating pressure of 100 PSI (689.48 kPa) and functions reliably across a wide temperature range from -40°C to 125°C.

Pressure Sensors Transducers Feature Summary

• Digital I2C output interface for direct microcontroller integration
• Media-isolated design suitable for harsh industrial environments
• Integrated temperature compensation for enhanced accuracy
• Stainless steel construction for durability

Pressure Sensors Transducers Applications

• Industrial automation systems
• HVAC monitoring
• Medical equipment
• Process control instrumentation

Pressure Sensors Transducers Procurement Notes

Verify the specific suffix codes on the component marking against official datasheets to confirm exact pressure rating and interface configuration. Ensure that the ordering part number matches the required package style and lead termination type. Cross-reference the manufacturer's latest revision history to confirm compatibility with existing system designs before finalizing procurement orders.

Pressure Sensors Transducers Selection Notes

Select this model when a digital I2C interface is required for absolute pressure measurement up to 100 PSI. Consider the cylindrical form factor and wire lead termination for board-level integration where space constraints allow. Evaluate the operating temperature range and media compatibility to ensure suitability for the specific application environment and fluid types involved in the system design.

Pressure Sensors Transducers Part Context

This component belongs to the NPI-19 series of harsh environment digital pressure sensors. The series offers various pressure ranges and interface options tailored for industrial applications. The NPI-19A variant specifically denotes an absolute pressure sensing capability within this family, providing standardized performance metrics for reliable data acquisition in demanding operational conditions.

Pressure Sensors Transducers Replacement Considerations

NPI-19J-100G2

Pressure Sensors Transducers FAQ

What is the pressure type for the NPI-19A-100G2?

It is an absolute pressure sensor.

Does the sensor include temperature compensation?

Yes, it features integrated temperature compensation.
