NSC5072D-40M

Overview

The NSC5072D-40M is a standard CMOS oscillator manufactured by NDK (NIHON DEMPA KOGYO CO., LTD). It operates at a nominal frequency of 40 MHz and utilizes a 3.3V supply voltage. The device features a standby or power-down function for energy management. It is housed in a compact 4-SMD, No Lead surface-mount package, suitable for automated assembly processes.

Feature Summary

• Integrated standby mode for power reduction
• CMOS output signal compatibility
• Surface-mount package design

Applications

• Digital clock generation circuits
• Microcontroller system timing references
• Communication interface synchronization

Procurement Notes

Verify the specific operating temperature range and load capacitance requirements against the target application circuit before ordering. Confirm that the 3.3V supply voltage aligns with the system power architecture. Ensure the 4-SMD footprint matches the PCB land pattern to guarantee proper solder joint integrity during assembly.

Selection Notes

Select this component when a low-profile, surface-mount oscillator with integrated power management is required. The CMOS output simplifies interfacing with digital logic without additional buffering. Consider the 40 MHz frequency stability needs and ensure the package dimensions fit within the spatial constraints of the electronic enclosure.

Part Context

This part belongs to NDK's series of standard crystal oscillators designed for general-purpose timing applications. It complements the manufacturer's portfolio of SAW devices and other resonator products, offering a reliable solution for systems requiring precise frequency generation with minimal board space consumption.

Replacement Considerations

NSC5004D-40M
