NSC5083D-49.152M

Overview

The NSC5083D-49.152M is a standard CMOS oscillator manufactured by NDK (NIHON DEMPA KOGYO CO., LTD). It operates at a nominal frequency of 49.152 MHz with a supply voltage of 3.3V. The device features a standby function for power management and utilizes a 4-SMD, no-lead package. It supports an operating temperature range of -40°C to 85°C.

Feature Summary

• CMOS output signal generation
• Integrated standby mode for power reduction
• Ultra-low phase noise characteristics

Applications

• High-quality audio systems
• Embedded system clocking
• Industrial automation control units

Procurement Notes

Verify the specific frequency tolerance and load capacitance requirements against the target circuit design before procurement. Confirm that the 3.3V supply voltage aligns with the system's power rails. Ensure the 4-SMD footprint matches the PCB layout specifications to guarantee proper surface-mount assembly and electrical connectivity.

Selection Notes

Select this component when ultra-low phase noise is critical for signal integrity in audio or precision applications. The integrated standby feature makes it suitable for battery-powered or energy-efficient designs. Verify compatibility with the host controller's input logic levels and ensure the operating temperature range meets environmental constraints.

Part Context

This part belongs to the NSC5083D series of standard oscillators from NDK. It is designed for applications requiring stable clock signals with minimal jitter. The series typically offers various frequency options within a compact surface-mount form factor, catering to modern electronic design constraints.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation.
