NSCSAAN004NDUNV

Description：SENSOR 0.15PSID 0.19" .262V 4SIP
Series：TruStability® NSC
Mfr：Honeywell Sensing and Productivity Solutions
Package：Bulk

SKU:06bed9ce860c Category: Pressure Sensors, Transducers Brand: Honeywell Sensing and Productivity Solutions

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

NSCSAAN004NDUNV is listed in the Pressure Sensors Transducers range at ChipApex. The manufacturer field lists Honeywell Sensing and Productivity Solutions. Its product description is SENSOR 0.15PSID 0.19" .262V 4SIP. Review the specifications below when checking this part for your BOM.

Pressure Sensors Transducers specifications for NSCSAAN004NDUNV

Description：SENSOR 0.15PSID 0.19" .262V 4SIP
Series：TruStability® NSC
Mfr：Honeywell Sensing and Productivity Solutions
Package：Bulk
Applications：Board Mount
Pressure Type：Differential
Operating Pressure：±0.15PSI (±1kPa)
Output Type：Wheatstone Bridge
Output：0 mV ~ 262 mV (5V)
Accuracy：±0.25%
Voltage - Supply：2.7V ~ 6.5V
Port Size：Male - 0.19" (4.93mm) Tube, Dual
Port Style：Barbed
Features：-
Termination Style：PC Pin
Maximum Pressure：±9.76PSI (±67.27kPa)
Operating Temperature：-40°C ~ 85°C
Mounting Type：Through Hole
Package / Case：4-SIP, Dual Ports, Opposite Sides
Supplier Device Package：4-SIP
Grade：-
Qualification：-

Pressure Sensors Transducers datasheet and documents for NSCSAAN004NDUNV

NSCSAAN004NDUNV

Pressure Sensors Transducers Overview

The NSCSAAN004NDUNV is a differential pressure sensor from the TruStability NSC series, manufactured by Honeywell Sensing and Productivity Solutions. It features a Wheatstone bridge output ranging from 0 mV to 262 mV at 5V supply. The device operates within a voltage range of 2.7V to 6.5V and supports an operating temperature of -40°C to 85°C. It utilizes a 4-SIP package with dual ports on opposite sides and PC pin termination for through-hole board mounting.

Pressure Sensors Transducers Feature Summary

High accuracy performance with ±0.25% precision
Temperature compensated silicon technology
Dual port configuration on opposite sides

Pressure Sensors Transducers Applications

Board mount installations
HVAC systems
Medical devices
Industrial automation

Pressure Sensors Transducers Procurement Notes

Verify that the replacement part matches the required supply voltage and output sensitivity specifications. Confirm physical compatibility of the 4-SIP package and dual-port orientation. Ensure the new component meets the necessary operating temperature range and accuracy requirements for the specific application environment before integration.

Pressure Sensors Transducers Selection Notes

Select this component for applications requiring high-precision differential pressure measurement with a compact form factor. Consider the 2.7V to 6.5V supply range and 0-262mV output when designing signal conditioning circuits. Evaluate the need for through-hole mounting and dual-port accessibility during mechanical design phases.

Pressure Sensors Transducers Part Context

This sensor belongs to the TruStability NSC series, representing Honeywell's advanced silicon pressure sensing technology. The series is designed for reliability in demanding environments, offering temperature compensation and high accuracy. The NSC line provides various pressure ranges and package options to suit diverse industrial and commercial sensing needs.
