NSCSHHN010NDUNV

Pressure Sensors Transducers Overview

The NSCSHHN010NDUNV is a differential pressure sensor from the TruStability NSC series. It features a ±0.36 PSI (±2.49 kPa) working pressure range with a maximum pressure of ±5 PSI. The device outputs an analog signal of 0 mV to 78.5 mV at 5V excitation, with a supply voltage range of 1.5V to 12V. Accuracy is rated at ±0.36%. It utilizes a 4-SIP dual-port package with male 0.16-inch tubes on the same side, designed for through-hole board mounting.

Pressure Sensors Transducers Feature Summary

• High-precision differential pressure sensing with ±0.36% accuracy
• Integrated dual-port design with male tubing connections
• Wide supply voltage compatibility from 1.5V to 12V
• Robust construction suitable for industrial environments

Pressure Sensors Transducers Applications

• Industrial automation systems
• HVAC monitoring and control
• Gas detection equipment
• Emissions analysis and monitoring

Pressure Sensors Transducers Procurement Notes

Verify the exact model number NSCSHHN010NDUNV against official Honeywell documentation to ensure correct pressure rating and port configuration. Confirm that the required supply voltage falls within the 1.5V to 12V range for your specific application. Check for RoHS compliance status if environmental regulations apply. Ensure mechanical fitment matches the 4-SIP dual-port package dimensions.

Pressure Sensors Transducers Selection Notes

Select this component when precise low-pressure differential measurement is required in compact spaces. The dual-port same-side configuration simplifies plumbing compared to opposite-side ports. Consider the ±0.36% accuracy for applications demanding high reliability. Verify that the operating temperature range of -40°C to 85°C meets environmental conditions.

Pressure Sensors Transducers Part Context

This part belongs to the TruStability NSC series, which offers advanced sensing solutions for industrial safety and productivity. The series is known for robust performance in harsh environments. The NSC line provides various pressure ranges and port configurations to suit different system requirements while maintaining consistent quality standards.

Pressure Sensors Transducers Replacement Considerations

No direct substitute parts are listed in the provided documentation. Consult Honeywell for potential obsolescence management or alternative models within the NSC series that match the required pressure range and output characteristics.
