NSCSMNN150PDUNV

Pressure Sensors Transducers Overview

The NSCSMNN150PDUNV is a differential pressure sensor from the TruStability NSC series, manufactured by Honeywell Sensing and Productivity Solutions. It features an unamplified, uncompensated Wheatstone bridge output with a sensitivity of 0mV to 258.5mV at 5V supply. The device has a working pressure range of ±150PSI (±1034.21kPa) and a maximum pressure rating of ±250PSI (±1723.69kPa). It operates on a supply voltage of 1.5V to 12V and functions within a temperature range of -40°C to 85°C. Accuracy is specified at ±0.25%. The component utilizes an 8-SMD, J-lead surface mount package for board mounting applications.

Pressure Sensors Transducers Feature Summary

• Differential pressure sensing capability with high accuracy
• Unamplified Wheatstone bridge output interface
• Wide operating supply voltage range
• Surface mount J-lead packaging for automated assembly

Pressure Sensors Transducers Applications

• Board mount pressure measurement systems
• Industrial sensor modules requiring differential pressure data
• Electronic assemblies utilizing surface mount technology

Pressure Sensors Transducers Procurement Notes

Verify the specific suffix UNV against official Honeywell documentation to confirm the exact variant characteristics, as ordering suffixes define critical electrical and mechanical parameters. Confirm current availability status directly with authorized distributors or the manufacturer, as component lifecycle stages may affect procurement options. Ensure that the selected part number matches the required pressure range and package type for the intended design implementation.

Pressure Sensors Transducers Selection Notes

Select this component when a differential pressure measurement is required in a surface mount configuration. The unamplified output necessitates external signal conditioning circuitry for voltage-based applications. Verify that the system power supply falls within the 1.5V to 12V range and that the mechanical layout accommodates the 8-SMD J-lead footprint. Consider the ±0.25% accuracy specification against application tolerance requirements.

Pressure Sensors Transducers Part Context

This part belongs to the TruStability NSC series, which provides silicon-based pressure sensors designed for board-level integration. The series includes various configurations for absolute, gauge, and differential pressure measurements. The NSC line typically offers unamplified or amplified outputs depending on the specific model suffix, catering to diverse signal processing needs in compact electronic designs.

Pressure Sensors Transducers Replacement Considerations

Consult the official TSC/NSC Datasheet for qualified alternative part numbers within the same family. Substitutes must match the differential pressure type, ±150PSI range, and 8-SMD J-lead package. Verify compatibility of pinout and electrical characteristics before replacement.
