Product Detailed Parameters
- Description：OPTOISOLATOR 8-SMD GW
- Series：-
- Mfr：SHARP/Socle Technology
- Package：Tape & Reel (TR)
- Number of Channels：-
- Voltage - Isolation：-
- Current Transfer Ratio (Min)：-
- Current Transfer Ratio (Max)：-
- Turn On / Turn Off Time (Typ)：-
- Rise / Fall Time (Typ)：-
- Input Type：-
- Output Type：-
- Voltage - Output (Max)：-
- Current - Output / Channel：-
- Voltage - Forward (Vf) (Typ)：-
- Current - DC Forward (If) (Max)：-
- Vce Saturation (Max)：-
- Operating Temperature：-
- Mounting Type：Surface Mount
- Package / Case：8-SMD, Gull Wing
- Supplier Device Package：8-SMD Gull Wing
- Grade：-
- Qualification：-
Download product information
Overview
The PC925LENIP0F is a high-speed, single-channel logic output optocoupler manufactured by Sharp. It integrates an infrared LED with an OPIC (Optically Coupled Integrated Circuit) chip, housed in an 8-pin SOP package with a 2.54mm pitch. The device features a peak output current of 2.5A and supports a working voltage range of 15V to 30V. Key electrical parameters include a maximum propagation delay of 500ns for both tpLH and tpHL, a common-mode transient immunity of 15kV/us, and an isolation voltage of 5kVrms. It operates within a temperature range of -40°C to +100°C.
Feature Summary
- High-speed response with a maximum propagation delay of 500ns
- Robust isolation capability rated at 5kVrms between input and output
- Integrated UV-lock feature for enhanced noise immunity
- Capable of driving loads with a peak output current up to 2.5A
Applications
- Gate drive circuits for power switching devices
- Industrial control systems requiring signal isolation
- Communication equipment interfaces
- Power supply feedback loops
Procurement Notes
Verify the specific ordering suffix against the manufacturer's official documentation to ensure correct packaging and pin configuration. Confirm that the SOP-8-2.54mm package variant matches the intended PCB footprint requirements. Cross-reference the component marking with the datasheet to authenticate the source and avoid counterfeit components during acquisition.
Selection Notes
Select this component when high-speed signal transmission is required alongside strong isolation capabilities. The 2.5A peak output current makes it suitable for direct gate driving applications without additional buffer stages. Ensure the operating environment remains within the specified -40°C to +100°C range to maintain performance reliability and longevity.
Part Context
This part belongs to Sharp's PC925 series of high-speed optocouplers designed for demanding industrial and commercial applications. The series utilizes OPIC technology to achieve fast response times and high noise immunity. The PC925LENIP0F specifically denotes the SOP-8 package variant, distinguishing it from DIP or other form factors within the same functional family.
Replacement Considerations
Consult official substitution lists for compatible alternatives. Verify pinout compatibility and electrical parameter equivalence before replacing the component in existing designs.
