PE51207

Description：3 DBI PCB 2400-2500 MHZ UMCX
Series：-
Mfr：Pasternack
Package：Bag

SKU:d05b22093bc2 Category: RF Antennas Brand: Pasternack

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

PE51207 is listed in the Antennas RF range at ChipApex. The manufacturer field lists Pasternack. Its product description is 3 DBI PCB 2400-2500 MHZ UMCX. Review the specifications below when checking this part for your BOM.

Antennas RF specifications for PE51207

Description：3 DBI PCB 2400-2500 MHZ UMCX
Series：-
Mfr：Pasternack
Package：Bag
RF Family/Standard：Bluetooth, WiFi
Frequency Group：UHF (2GHz ~ 3GHz)
Frequency (Center/Band)：2.45GHz
Frequency Range：2.4GHz ~ 2.5GHz
Antenna Type：PCB Trace
Number of Bands：1
VSWR：2
Return Loss：-
Gain：3dBi
Features：Cable - 100mm
Termination：U.FL (UMCX), I-PEX
Ingress Protection：-
Grade：-
Qualification：-
Mounting Type：Surface Mount
Height (Max)：-
Applications：Bluetooth, WLAN
Power - Max：-
