PE70A9037

$1,564.68

Description：Negative Slope Equalizer, 18 GHz
Series：-
Mfr：Pasternack
Package：Retail Package

SKU:350b594a5281 Category: RF Misc ICs and Modules Brand: Pasternack

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：Negative Slope Equalizer, 18 GHz
Series：-
Mfr：Pasternack
Package：Retail Package
Function：Linear Equalizer
Frequency：18GHz ~ 26.5GHz
RF Type：General Purpose
Secondary Attributes：SMA Connectors
Mounting Type：Chassis Mount
Package / Case：SMA In-Line Module
Supplier Device Package：-
Grade：-
Qualification：-

Download product information

PE70A9037

Overview

The PE70A9037 is a negative slope equalizer module manufactured by Pasternack. It operates within a frequency range of 18 GHz to 26 GHz. The component provides a fixed equalizing value of 4 dB and exhibits an insertion loss of 0.9 dB. It supports a maximum input power of 250 mW. The device utilizes SMA connectors for interface connectivity.

Feature Summary

Negative slope signal conditioning
Fixed attenuation response
SMA connector interface

Applications

RF signal path compensation
High-frequency circuit integration
General purpose RF systems

Procurement Notes

Verify the specific datasheet version for the PE70A9037 to confirm mechanical dimensions and electrical tolerances. Ensure compatibility with existing SMA interfaces in the target assembly. Check for any regional distribution restrictions or supply limitations that may affect procurement timelines.

Selection Notes

Select this component when a fixed negative slope equalization is required between 18 GHz and 26 GHz. Consider the 0.9 dB insertion loss and 250 mW power handling limits during system design. Verify that the SMA connector type matches the board layout requirements.

Part Context

This part belongs to Pasternack's linear equalizer series designed for RF applications. It addresses signal degradation issues in high-frequency transmission lines. The module integrates passive components to achieve the specified attenuation characteristics without active power sources.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Consult Pasternack engineering for potential cross-reference options if this specific model is discontinued or unavailable.
