PE82P2004

Overview

The PE82P2004 is an analog phase shifter manufactured by Pasternack, designed for RF and wireless applications. It operates within a frequency range of 2 GHz to 4 GHz and provides a full 360-degree phase shift capability. The device accepts a control voltage input ranging from 0V to +10V to adjust the phase output. It supports a maximum input power level of +27 dBm. This component is categorized under RF miscellaneous ICs and modules, serving as a general-purpose solution for phase adjustment in signal processing systems.

Feature Summary

• Provides continuous 360-degree analog phase shifting across the operational bandwidth
• Utilizes a linear 0V to +10V control voltage interface for precise phase adjustment
• Supports high input power levels up to +27 dBm for robust signal handling

Applications

• RF signal processing systems requiring dynamic phase alignment
• Wireless communication infrastructure components
• Test and measurement equipment calibration circuits

Procurement Notes

Verify the specific datasheet version and manufacturer specifications before integration. Confirm that the control voltage requirements and maximum input power limits align with your system design parameters. Ensure compatibility with the 2 GHz to 4 GHz operating frequency range. Check for any regional distribution restrictions or supply limitations associated with this component.

Selection Notes

Select this component when a wideband analog phase shifter is required for frequencies between 2 GHz and 4 GHz. Consider the +27 dBm power handling capability if high-power signal paths are involved. The 0V to +10V control interface should match your available drive electronics. Evaluate the physical package and mounting requirements against your PCB layout constraints.

Part Context

This part belongs to Pasternack's portfolio of RF miscellaneous integrated circuits and modules. It functions as a general-purpose phase shifter within their broader lineup of RF components. The device complements other signal conditioning products offered by the manufacturer, targeting applications needing reliable phase control in microwave frequency bands.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Verify functional equivalence carefully if considering alternative manufacturers.
