PE88X2019

Overview

The Pasternack PE88X2019 is an active signal conditioning frequency multiplier designed for microwave applications. It functions as a 3x frequency multiplier, converting input signals to an output frequency range of 2100 MHz to 3000 MHz. The device provides a conversion gain of 12 dB and utilizes SMA connectors for interface connectivity. This component is engineered for general-purpose RF signal processing tasks requiring precise frequency multiplication within the specified UHF band.

Feature Summary

• Active frequency multiplication with a fixed 3x ratio
• Integrated signal conditioning for stable output generation
• SMA connector interface for standard RF integration

Applications

• General-purpose RF signal processing systems
• Microwave communication equipment
• Test and measurement instrumentation

Procurement Notes

Verify the specific datasheet version and manufacturing lot details upon order confirmation. Confirm that the SMA connector polarity and mating requirements align with your system design. Ensure environmental operating conditions match the component specifications. Request updated availability status directly from the manufacturer or authorized distributor prior to finalizing procurement plans.

Selection Notes

Select this component when a fixed 3x multiplication ratio is required within the 2100 MHz to 3000 MHz output range. The 12 dB conversion gain supports moderate signal amplification needs. Verify that the SMA interface compatibility matches existing board layouts. Consider thermal management requirements based on the active circuitry involved in the frequency multiplication process.

Part Context

This model belongs to Pasternack's active signal conditioning series, which integrates frequency multiplication capabilities into compact modules. These components are typically used to generate higher frequency signals from lower frequency sources without complex external synthesizer circuits. The product line focuses on providing reliable, plug-and-play solutions for RF engineers designing microwave subsystems.

FAQ

What is the multiplication factor of the PE88X2019?

The PE88X2019 operates as a 3x frequency multiplier.

Does the PE88X2019 include built-in amplification?

Yes, it provides a conversion gain of 12 dB during the frequency multiplication process.
