PG2794

Pressure Sensors Transducers Overview

The PG2794 is an electronic pressure sensor featuring a flush-mounted design with an integrated analog display, pressure switch, and transmitter in one unit. It provides excellent readability over long distances via a rotatable LED bar graph display for setpoint indication. The device supports vacuum and relative pressure measurement with a range of -100 kPa to 100 kPa (-14.5 PSI to 14.5 PSI). It offers a 4 mA to 20 mA analog output and one programmable digital switching output. The sensor utilizes a G 1 male thread connection and operates on 18–32 V DC.

Pressure Sensors Transducers Feature Summary

• Integrates analog display, pressure switch, and transmitter into a single unit for simplified installation
• Features a rotatable display with LED bar graph for clear setpoint indication from a distance
• Constructed with a hygienic stainless steel housing suitable for sanitary applications
• Designed for flush mounting to enable flat pipe connections during CIP and SIP processes

Pressure Sensors Transducers Applications

• Food and beverage processing industries requiring hygienic standards
• Clean-in-Place (CIP) systems
• Sterilize-in-Place (SIP) processes
• Industrial automation monitoring of liquid and gas media

Pressure Sensors Transducers Procurement Notes

Verify the specific ordering suffix to confirm thread type, process connection details, and cable or connector configuration. Ensure the selected variant matches the required pressure range and electrical interface specifications for the target application. Confirm availability as this model may be subject to discontinuation or replacement by newer series variants.

Pressure Sensors Transducers Selection Notes

Select this sensor for applications requiring simultaneous visual monitoring and signal transmission. The flush design is critical for sanitary environments where crevices must be avoided. Verify compatibility with the medium's temperature and chemical properties against the stated limits. Ensure the supply voltage matches the 18–32 V DC requirement and that the G 1 thread fits the existing piping infrastructure.

Pressure Sensors Transducers Part Context

Produced by ifm efector, Inc., a subsidiary of ifm electronic GmbH, Germany. The company specializes in industrial sensors and controls for automation, including pressure, flow, and vision sensors. The PG2794 belongs to the pressure sensor category designed for robust industrial use with IO-Link capabilities in modern iterations.

Pressure Sensors Transducers Replacement Considerations

The PG1704 is identified as a potential substitute product. Technical parameters may differ between the original and replacement models. Verify functional equivalence regarding pressure range, output signals, and mechanical dimensions before implementation.
