PPT7X-125GIT-MOD-PN2-B

Pressure Sensors Transducers Overview

The PPT7X-125GIT-MOD-PN2-B is a sealed gauge pressure transducer from the Phoenix Sensors PPT7X series, rated for 125 PSI (861.84 kPa). It features an I2C digital interface and operates on a supply voltage of 2.7V to 5.5V. The unit utilizes a stainless steel port suitable for liquid or gas media measurement. Physical specifications include a male thread connection with a length of 0.36 inches (9.14mm) and a 1.5-inch cable termination equipped with a connector.

Pressure Sensors Transducers Feature Summary

• Delivers high-level digital output via an I2C interface for direct microcontroller integration.
• Constructed with a stainless steel port design compatible with both liquid and gas media.
• Configured as a sealed gauge sensor for accurate pressure measurement relative to atmospheric pressure.

Pressure Sensors Transducers Applications

• Industrial automation systems requiring compact digital pressure monitoring.
• Medical devices needing precise small-form-factor pressure sensing.
• Automotive applications involving gas or liquid pressure measurement.

Pressure Sensors Transducers Procurement Notes

Verify the specific ordering suffix against the manufacturer's current documentation to ensure the correct interface version and cable configuration. Confirm that the 125 PSI rating aligns with the maximum operating pressure of the target application. Check for any recent updates regarding the I2C address mapping or pinout definitions in the official datasheet before finalizing procurement orders.

Pressure Sensors Transducers Selection Notes

Select this model when a small footprint and digital I2C communication are required for pressure monitoring. Ensure the system power supply falls within the 2.7V to 5.5V range. Verify that the sealed gauge pressure type matches the application's reference pressure requirements. Confirm compatibility with the 1.5-inch cable length and connector style for the installation environment.

Pressure Sensors Transducers Part Context

This component belongs to the PPT7X series of small high-level digital pressure transducers manufactured by Phoenix Sensors. The series is designed for OEM applications requiring accuracy and durability in compact spaces. The PPT7X line supports various pressure ranges and interfaces, with this specific variant focusing on sealed gauge measurement and I2C connectivity.

Pressure Sensors Transducers Replacement Considerations

Consult the official Phoenix Sensors catalog for cross-reference data. No public substitute part numbers are confirmed in the provided documentation. Verify mechanical thread dimensions and electrical interface compatibility if considering alternative models from other manufacturers.
