Product Detailed Parameters
- Description：General Purpose Fixed Range Pres
- Series：PT20
- Mfr：NOSHOK, Inc.
- Package：Bulk
- Applications：Industrial
- Pressure Type：Gauge
- Operating Pressure：-
- Output Type：Analog Current, Analog Voltage
- Output：-
- Accuracy：±0.5%
- Voltage - Supply：-
- Port Size：Male - G1/4" (6.35mm) B
- Port Style：Threaded
- Features：-
- Termination Style：DIN EN 175301-803 Form A
- Maximum Pressure：-
- Operating Temperature：-
- Mounting Type：-
- Package / Case：-
- Supplier Device Package：-
- Grade：-
- Qualification：-
Download product information
Overview
The NOSHOK PT20-6BARG-1-1-10-8 is a pressure transmitter designed for industrial process monitoring. It features a 4 to 20 mA analog output signal and operates on a DC power supply ranging from 10.5 to 35 VDC. The unit provides a gauge pressure measurement range of 0 to 6 bar, with an accuracy class of 0.5% full scale. It utilizes a stainless steel wetted material construction for durability in harsh environments. The device includes a standard 1/4 NPT male process connection for secure installation. Electrical connectivity is achieved via a 4-pin M12 connector, facilitating integration into control systems.
Feature Summary
- Provides stable 4-20 mA current loop output for reliable data transmission
- Constructed with stainless steel components for corrosion resistance
- Features a compact design suitable for space-constrained installations
- Equipped with a standardized M12 electrical interface
Applications
- Hydraulic system pressure monitoring
- Pneumatic circuit diagnostics
- Industrial pump and compressor protection
- Process automation control loops
Procurement Notes
Verify the specific model suffixes against the manufacturer's current configuration guide to ensure compatibility with required process connections and electrical interfaces. Confirm that the operating temperature range and media compatibility align with the intended application environment before finalizing the order.
Selection Notes
Select this model when a gauge pressure reference is required for low-pressure applications up to 6 bar. Ensure the process medium is compatible with stainless steel wetted parts. Verify that the available power supply falls within the specified 10.5 to 35 VDC range and that the control system supports 4-20 mA input signals.
Part Context
This component belongs to the PT20 series of pressure transmitters manufactured by NOSHOK, Inc. The series is engineered for general industrial applications requiring robust performance and accurate measurement. The PT20 line typically offers various process connection options and electrical configurations to meet diverse system requirements.
Replacement Considerations
Consult official cross-reference guides or manufacturer documentation for direct replacements. Verify mechanical dimensions, mounting styles, and electrical pinouts to ensure interchangeability without modifying existing infrastructure.
