PT20-750PSIG-1-5-2-25-ST8-CC

Overview

The PT20-750PSIG-1-5-2-25-ST8-CC is a general-purpose fixed-range pressure transmitter manufactured by NOSHOK, Inc. It features a gauge pressure measurement range of 0 to 750 psi (0 to 5171 kPa). The device provides an analog voltage output signal ranging from 0 V to 10 V. It utilizes a male 1/4-inch NPT process connection for installation. The unit is designed for industrial applications requiring reliable pressure monitoring.

Feature Summary

• Provides a linear 0 V to 10 V analog output signal corresponding to the measured pressure range.
• Features a robust male 1/4-inch NPT threaded process connection for secure mounting.
• Designed as a general-purpose transmitter suitable for various industrial environments.

Applications

• Industrial process control systems
• Hydraulic and pneumatic machinery monitoring
• General purpose pressure transmission in manufacturing

Procurement Notes

Verify the specific model suffixes against official NOSHOK documentation to ensure correct output type, connection size, and media compatibility. Confirm that the 0-750 psi gauge range aligns with system requirements. Check for any environmental certifications or material specifications required for the intended application environment.

Selection Notes

Select this model when a 0-10 V analog output is required for pressures up to 750 psi. Ensure the 1/4-inch NPT port matches the existing piping or panel configuration. Consider the operating temperature range and media compatibility with wetted materials before finalizing the selection for critical applications.

Part Context

This component belongs to the PT20 series of pressure transmitters from NOSHOK, Inc., which are characterized by their general-purpose design and fixed range capabilities. The series is engineered for durability and accuracy in industrial settings, offering standardized electrical outputs and mechanical connections for easy integration into broader control systems.
