PT40-1000psig-1-1-45-80-ST8-CC is listed in the Pressure Sensors Transducers range at ChipApex. The manufacturer field lists NOSHOK, Inc.. Its product description is High Accuracy Fixed Range Pressu. Review the specifications below when checking this part for your BOM.
Pressure Sensors Transducers specifications for PT40-1000psig-1-1-45-80-ST8-CC
- Description：High Accuracy Fixed Range Pressu
- Series：PT40
- Mfr：NOSHOK, Inc.
- Package：Bulk
- Applications：Industrial
- Pressure Type：Gauge
- Operating Pressure：0PSI ~ 1000PSI (0kPa ~ 6894.76kPa)
- Output Type：Analog Current
- Output：4 ~ 20 mA
- Accuracy：±0.25%
- Voltage - Supply：10V ~ 30V
- Port Size：Male - 7/16" (11.11mm) SAE
- Port Style：Threaded
- Features：-
- Termination Style：DIN EN 175301-803 Form A
- Maximum Pressure：1000PSI (6894.75kPa)
- Operating Temperature：-30°C ~ 100°C
- Mounting Type：-
- Package / Case：-
- Supplier Device Package：-
- Grade：-
- Qualification：-
Pressure Sensors Transducers datasheet and documents for PT40-1000psig-1-1-45-80-ST8-CC
Pressure Sensors Transducers Overview
The NOSHOK PT40-1000psig-1-1-45-80-ST8-CC is a high-accuracy fixed-range pressure transmitter designed for industrial applications. It features a gauge pressure range of 0 to 1000 psi (0 to 6894.76 kPa). The device offers an accuracy of ±0.25% of span, with an optional ±0.125% accuracy level available. It provides a fast response time of less than 1 millisecond. The unit utilizes a specific electrical connection interface and output signal configuration as defined by its model suffixes.
Pressure Sensors Transducers Feature Summary
- High measurement accuracy with standard ±0.25% of span performance
- Rapid dynamic response suitable for transient pressure monitoring
- Robust construction for demanding industrial hydraulic environments
Pressure Sensors Transducers Applications
- Hydraulic system monitoring
- Industrial process control
- Pressure transducer integration in machinery
Pressure Sensors Transducers Procurement Notes
Verify the complete part number against official NOSHOK documentation to ensure correct configuration of pressure range, electrical connections, and output signals. Confirm environmental ratings and material compatibility with the intended medium. Cross-reference the specific suffix codes for accurate interface and mounting requirements before ordering.
Pressure Sensors Transducers Selection Notes
Select this model when precise pressure measurement is required in hydraulic systems. Consider the optional higher accuracy specification if tighter tolerances are necessary. Ensure the physical dimensions and electrical interfaces match the installation constraints. Evaluate the response time requirements against the dynamics of the monitored system.
Pressure Sensors Transducers Part Context
This component belongs to the NOSHOK PT40 series of pressure transmitters and transducers. The series is characterized by high accuracy and fast response times, making it suitable for critical industrial applications. The PT40 line includes various configurations to meet different pressure ranges and electrical interface needs.
Pressure Sensors Transducers Replacement Considerations
Consult official NOSHOK documentation for confirmed substitute part numbers. Verify that any replacement matches the exact pressure range, accuracy class, and electrical specifications. Generic equivalents may not provide the same performance characteristics or reliability standards.
