PT40-1000psig-1-2-45-14-CC

$447.08

Description：High Accuracy Fixed Range Pressu
Series：PT40
Mfr：NOSHOK, Inc.
Package：Bulk

SKU:cafc66533bbc Category: Pressure Sensors, Transducers Brand: NOSHOK, Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

PT40-1000psig-1-2-45-14-CC is listed in the Pressure Sensors Transducers range at ChipApex. The manufacturer field lists NOSHOK, Inc.. Its product description is High Accuracy Fixed Range Pressu. Review the specifications below when checking this part for your BOM.

Pressure Sensors Transducers specifications for PT40-1000psig-1-2-45-14-CC

Description：High Accuracy Fixed Range Pressu
Series：PT40
Mfr：NOSHOK, Inc.
Package：Bulk
Applications：Industrial
Pressure Type：Gauge
Operating Pressure：0PSI ~ 1000PSI (0kPa ~ 6894.76kPa)
Output Type：Analog Voltage
Output：0 V ~ 5 V
Accuracy：±0.25%
Voltage - Supply：10V ~ 30V
Port Size：Male - 7/16" (11.11mm) SAE
Port Style：Threaded
Features：-
Termination Style：DIN EN 175301-803 Form A with 1/2" NPT Female Conduit
Maximum Pressure：1000PSI (6894.75kPa)
Operating Temperature：-30°C ~ 100°C
Mounting Type：-
Package / Case：-
Supplier Device Package：-
Grade：-
Qualification：-

Pressure Sensors Transducers datasheet and documents for PT40-1000psig-1-2-45-14-CC

PT40-1000psig-1-2-45-14-CC

Pressure Sensors Transducers Overview

The NOSHOK PT40-1000psig-1-2-45-14-CC is a high-accuracy industrial pressure transmitter featuring a 1000 psig gauge range. It utilizes a 4mA to 20mA, 2-wire output signal and operates on a 10V DC to 35V DC power requirement. The device offers ±0.25% of span accuracy with a response time under 1ms. Wetted parts are constructed from 316 and 13-8PH stainless steel. Environmental ratings include IP65 for DIN EN 175301-803 connectors and IP67 for M12 or bayonet interfaces.

Pressure Sensors Transducers Feature Summary

Field-adjustable offset and span capabilities
CE compliant design suppressing RFI, EMI, and ESD
RoHS compliant construction materials
Premium accuracy with fast response times

Pressure Sensors Transducers Applications

Hydraulics and pneumatics systems
Laboratory and test equipment
Mobile equipment monitoring
General industrial automation

Pressure Sensors Transducers Procurement Notes

Verify the specific ordering suffixes against official NOSHOK documentation to confirm the exact configuration. Ensure the selected model matches the required process connection, electrical interface, and media compatibility. Cross-reference the part number with current manufacturer catalogs to validate availability and technical specifications before procurement.

Pressure Sensors Transducers Selection Notes

Select this model based on the required 1000 psig gauge range and 4mA to 20mA output signal. Confirm that the operating temperature falls within the compensated range of 0°C to +80°C. Verify environmental protection requirements to choose between IP65 or IP67 connector options. Ensure power supply constraints align with the 10V DC to 35V DC input specification.

Pressure Sensors Transducers Part Context

The PT40 series represents NOSHOK's line of high-accuracy fixed-range transmitters and transducers. This product line supports gauge, compound, absolute, and vacuum ranges up to 15,000 psig. The series is designed for demanding industrial applications requiring reliable pressure measurement and signal transmission.
