PT40-1000psig-2-1-2-3-ST8

Pressure Sensors Transducers Overview

The NOSHOK PT40-1000psig-2-1-2-3-ST8 is a pressure transmitter designed for industrial process monitoring. It features a measurement range of 0 to 1000 psig and utilizes a 2-wire current loop interface. The unit provides a standard 4-20 mA output signal, powered by a DC supply voltage ranging from 10.5 to 45 volts. The device incorporates a stainless steel wetted materials construction to ensure durability against corrosive media. It includes an integrated LCD display for local parameter viewing and configuration. The transmitter is engineered for high stability and long-term reliability in demanding environments.

Pressure Sensors Transducers Feature Summary

• Integrated LCD display for local monitoring and configuration
• Stainless steel wetted materials for corrosion resistance
• Standard 4-20 mA two-wire current loop output
• High stability design for long-term industrial reliability

Pressure Sensors Transducers Applications

• Industrial process control systems
• Hydraulic and pneumatic machinery monitoring
• Fluid level measurement applications
• Compressed air system management

Pressure Sensors Transducers Procurement Notes

Verify the specific process connection size and thread type required for your installation before ordering. Confirm that the operating temperature range of the medium is compatible with the transmitter's specified limits. Ensure the power supply voltage falls within the 10.5 to 45 VDC range. Check if the ST8 suffix indicates a specific calibration certificate or housing material variant required by your project specifications.

Pressure Sensors Transducers Selection Notes

Select this model when a compact transmitter with local readout capability is needed. The 1000 psig range suits moderate pressure applications. Consider the 4-20 mA output for compatibility with standard PLCs and DCS systems. Evaluate the wetted material compatibility with the specific fluid being measured to prevent chemical degradation.

Pressure Sensors Transducers Part Context

This component belongs to the NOSHOK PT40 series of pressure transmitters. This series is characterized by its robust stainless steel construction and versatile mounting options. The PT40 line is widely used across various industries requiring precise pressure feedback. The model number encodes specific electrical and mechanical configurations for tailored integration.

Pressure Sensors Transducers Replacement Considerations

Consult official NOSHOK documentation for direct cross-reference part numbers. Verify dimensional compatibility and electrical interface matching before substituting. Generic replacements may lack the integrated LCD display feature.
