Product Detailed Parameters
- Description：IGBT TRENCH FS 650V 76A TO247-3L
- Series：-
- Mfr：Panjit International Inc.
- Package：Tube
- IGBT Type：Trench Field Stop
- Voltage - Collector Emitter Breakdown (Max)：650 V
- Current - Collector (Ic) (Max)：76 A
- Current - Collector Pulsed (Icm)：120 A
- Vce(on) (Max) @ Vge, Ic：2.25V @ 15V, 40A
- Power - Max：220 W
- Switching Energy：330µJ (on), 120µJ (off)
- Input Type：Standard
- Gate Charge：65 nC
- Td (on/off) @ 25°C：14ns/96ns
- Test Condition：400V, 20A, 10Ohm, 15V
- Reverse Recovery Time (trr)：64 ns
- Operating Temperature：-40°C ~ 175°C (TJ)
- Mounting Type：Through Hole
- Package / Case：TO-247-3
- Supplier Device Package：TO247-3L
- Grade：-
- Qualification：-
Download product information
Overview
The PTGH4065S1_T0_00201 is a high-speed Field Stop Trench Insulated Gate Bipolar Transistor manufactured by Panjit International Inc. It features a collector-emitter voltage rating of 650V and a continuous collector current capacity of 46A. The device offers a low saturation voltage of 1.65V at a junction temperature of +25°C, supporting superior switching performance. It is housed in a TO-247-3L package with a power dissipation rating of 110W.
Feature Summary
- High-speed switching capabilities enabled by Field Stop Trench technology
- Low saturation voltage for improved efficiency
- Robust thermal performance suitable for high-power applications
Applications
- Motor control systems
- Switching power supplies
- Inverter circuits
Procurement Notes
Verify the specific ordering suffix to ensure compatibility with required packaging and manufacturing standards. Confirm that the component meets all necessary regulatory compliance requirements for the intended market. Cross-reference the manufacturer datasheet for detailed electrical characteristics and absolute maximum ratings before integration into design specifications.
Selection Notes
Select this component when high-speed switching and low conduction losses are critical. The 650V rating suits medium-voltage applications. Ensure the thermal management solution supports the 110W dissipation limit. Compare against standard trench IGBTs to evaluate the benefits of the Field Stop structure for specific circuit dynamics.
Part Context
This part belongs to Panjit's PTGH series of high-speed IGBTs. The series utilizes Trench Field Stop technology to optimize the trade-off between switching speed and saturation voltage. It is designed for general-purpose power switching applications requiring efficient energy conversion and reliable operation under high-frequency conditions.
Replacement Considerations
Direct substitutes include other 650V Field Stop Trench IGBTs in TO-247 packages from Panjit or competitors. Verify pinout compatibility and thermal resistance values. Check if alternative parts meet the same 46A current and 110W power dissipation requirements.
