R5F10E8CALA#U0

Microcontrollers Overview

The R5F10E8CALA#U0 is a 16-bit microcontroller from the Renesas RL78/G1A series. It features a 32 MHz CPU core with 48 kB of Flash program memory and 3 kB of RAM. The device operates within a voltage range of 1.6 V to 3.6 V and supports an industrial temperature range of -40°C to +105°C. It includes a 12-bit ADC with 24 channels, multiple communication interfaces including CSI, I2C, LIN, and UART, and provides 32 general-purpose I/O pins in a 48-LFQFP package.

Microcontrollers Feature Summary

• Integrates high-performance 16-bit CPU architecture with low power consumption capabilities for efficient energy management.
• Includes built-in security functions designed to detect hardware illegal operations and support safety standards.
• Features a high-resolution 12-bit analog-to-digital converter for precise signal acquisition.

Microcontrollers Applications

• Consumer electronics requiring secure data processing
• Industrial sensor nodes with communication needs
• Home appliance control units

Microcontrollers Procurement Notes

Verify the specific suffix #U0 against official Renesas documentation to confirm package type and temperature grade. Ensure compatibility with existing design constraints regarding the 48-pin LFQFP footprint and supply voltage requirements before finalizing procurement decisions.

Microcontrollers Selection Notes

Select this component when a balance of moderate memory capacity and robust security features is required. The RL78/G1A series offers a cost-effective solution for applications needing LIN bus support and multiple analog inputs without excessive pin count complexity.

Microcontrollers Part Context

This part belongs to the RL78/G1A family, which targets general-purpose MCU applications. The series emphasizes low power usage alongside sufficient processing power for embedded control tasks. It is positioned as a versatile option for both consumer and industrial markets.

Microcontrollers Replacement Considerations

Consult the RL78/G1A group user manual for cross-reference options. Verify pinout and peripheral compatibility with potential substitutes such as other members of the R5F10Exx series or newer generations within the same product line.
