R5F562TABGFK#V3

Microcontrollers Overview

The R5F562TABGFK#V3 is a 32-bit microcontroller from the Renesas RX62T series, utilizing the RX core architecture. It features 128 kB of program memory and 8 kB of data RAM within an LQFP-64 package. The device supports a maximum clock frequency of 100 MHz and operates with a supply voltage range of 4 V to 5.5 V. It provides 37 I/O pins and includes integrated interfaces such as CAN, I2C, SCI, and USB. The component is designed for industrial applications with a specified operating temperature range of -40°C to +85°C.

Microcontrollers Feature Summary

• Integrates high-speed 100 MHz processing capability with robust peripheral connectivity including CAN and USB.
• Supports flexible analog signal acquisition through multiple ADC channels with configurable resolution options.
• Provides comprehensive communication interface support suitable for complex embedded control systems.

Microcontrollers Applications

• Industrial automation controllers requiring reliable serial communication protocols
• Motor control systems utilizing CAN bus integration
• Data acquisition modules needing multi-channel analog input processing

Microcontrollers Procurement Notes

Verify the specific suffix designation against official Renesas documentation to confirm pin compatibility and electrical characteristics. Ensure that the LQFP-64 package dimensions align with your PCB footprint requirements. Cross-reference the manufacturing date code and RoHS compliance status with current distributor declarations to meet regulatory standards for your target market.

Microcontrollers Selection Notes

Select this component when a balance of moderate memory capacity and extensive peripheral integration is required. The RX62T series offers a cost-effective solution for applications not demanding the highest performance tiers of the RX family. Consider the 4V to 5.5V operating range for systems powered by standard industrial voltage rails rather than low-voltage logic supplies.

Microcontrollers Part Context

This part belongs to the RX62T family, which targets general-purpose embedded applications. The series emphasizes energy efficiency and peripheral richness. The RX core architecture delivers high instruction throughput while maintaining low power consumption profiles suitable for battery-operated or thermally constrained environments.

Microcontrollers Replacement Considerations

Consult official Renesas substitution guides for verified alternatives. Direct replacements must match the RX62T core, LQFP-64 package, and 128kB/8kB memory configuration. Verify that any substitute maintains identical pinout assignments and electrical specifications to ensure board-level compatibility without redesign.
