R6020ENX

$3.28

Description：MOSFET N-CH 600V 20A TO220FM
Series：-
Mfr：Rohm Semiconductor
Package：Bulk

SKU:4b3e96ea0d54 Category: Single FETs, MOSFETs Brand: Rohm Semiconductor

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

R6020ENX is listed in the Single FETs, MOSFETs range at ChipApex. The manufacturer field lists Rohm Semiconductor. Its product description is MOSFET N-CH 600V 20A TO220FM. Review the specifications below when checking this part for your BOM.

Single FETs, MOSFETs specifications for R6020ENX

Description：MOSFET N-CH 600V 20A TO220FM
Series：-
Mfr：Rohm Semiconductor
Package：Bulk
FET Type：N-Channel
Technology：MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)：600 V
Current - Continuous Drain (Id) @ 25°C：20A (Tc)
Drive Voltage (Max Rds On, Min Rds On)：10V
Rds On (Max) @ Id, Vgs：196mOhm @ 10A, 10V
Vgs(th) (Max) @ Id：4V @ 1mA
Gate Charge (Qg) (Max) @ Vgs：60 nC @ 10 V
Vgs (Max)：±20V
Input Capacitance (Ciss) (Max) @ Vds：1400 pF @ 25 V
FET Feature：-
Power Dissipation (Max)：50W (Tc)
Operating Temperature：150°C (TJ)
Grade：-
Qualification：-
Mounting Type：Through Hole
Supplier Device Package：TO-220FM
Package / Case：TO-220-3 Full Pack

Single FETs, MOSFETs datasheet and documents for R6020ENX

R6020ENX

Single FETs, MOSFETs Overview

The R6020ENX is an N-channel power MOSFET manufactured by ROHM Semiconductor, designed for switching applications. It features a 600V drain-source voltage rating and a continuous drain current of ±20A. The device offers a maximum on-state resistance of 0.196Ω at VGS=10V and supports a power dissipation of 68W at 25°C case temperature. Key electrical parameters include a total gate charge of 60nC and a reverse recovery time of 550ns. It operates within a junction temperature range of -55°C to +150°C.

Single FETs, MOSFETs Feature Summary

Low on-resistance for efficient conduction
Fast switching capability
Simplified drive circuit requirements
Easy parallel use configuration

Single FETs, MOSFETs Applications

Switching circuits

Single FETs, MOSFETs Procurement Notes

Verify the specific ordering suffix (C7G) against the manufacturer's latest documentation to ensure correct packaging type. Confirm RoHS compliance status and Pb-free plating specifications prior to integration. Cross-reference absolute maximum ratings with your system's thermal management design to prevent exceeding junction temperature limits during operation.

Single FETs, MOSFETs Selection Notes

Select this component when a 600V N-channel MOSFET with low on-resistance is required for general-purpose switching. Ensure the application environment remains within standard conditions, avoiding exposure to corrosive gases or direct sunlight. Verify that the drive circuit can support the specified gate threshold voltage and total gate charge characteristics for optimal performance.

Single FETs, MOSFETs Part Context

This part belongs to the R6020 series of N-channel power MOSFETs from ROHM Semiconductor. It utilizes the TO-220FM package for through-hole mounting. The series is characterized by low noise and high-speed switching capabilities, targeting power supply applications where efficiency and thermal performance are critical.
