S-8356Q50BD-OVJ-TFG
Search Product
Search Post
— IC芯片 | 连接器 | 传感器 | 被动器件 —
Consult the customer manager about the wholesale price.
consultation hotline：86-132-6715-2157
email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.
Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.
Product Detailed Parameters
- Description：IC REG CTRLR BOOST 6SNB
- Series：-
- Mfr：ABLIC Inc.
- Package：Tape & Reel (TR)
- Output Type：Transistor Driver
- Function：Step-Up
- Output Configuration：Positive
- Topology：Boost
- Number of Outputs：1
- Output Phases：1
- Voltage - Supply (Vcc/Vdd)：0.9V ~ 10V
- Frequency - Switching：600kHz
- Duty Cycle (Max)：78%
- Synchronous Rectifier：No
- Clock Sync：No
- Serial Interfaces：-
- Control Features：Enable
- Operating Temperature：-40°C ~ 85°C (TA)
- Mounting Type：Surface Mount
- Package / Case：6-VFDFN Exposed Pad
- Supplier Device Package：6-SNB (1.8x2.0)
Download product information
Overview
The S-8356Q50BD-OVJ-TFG is a single-output positive Boost DC-DC controller IC from ABLIC Inc. It operates with a selectable switching frequency of 600kHz and features a maximum duty cycle of 78%. The device utilizes a 6-SNB (1.8x2.0) package for surface mount installation. It is designed for efficient step-up voltage regulation in power management applications.
Feature Summary
- Single-output positive boost DC-DC controller configuration
- Selectable switching frequency operation at 600kHz
- Maximum duty cycle capability of 78%
- Compact 6-SNB surface mount package
Applications
- Portable electronic devices requiring step-up voltage regulation
- Battery-powered systems needing boosted output voltages
- General power management integrated circuits
Procurement Notes
Verify the specific ordering suffix OVJ-TFG to ensure correct packaging and tape/reel specifications. Confirm RoHS compliance status as Lead-free/RoHS Compliant through official manufacturer documentation or authorized distributor datasheets before procurement.
Selection Notes
Select this component when a compact boost controller with 600kHz selectable frequency is required. Ensure input voltage ranges match system requirements. The 6-SNB package size suits space-constrained designs. Verify compatibility with external inductor and capacitor selections for stable operation.
Part Context
This part belongs to the ABLIC Inc. Power Management (PMIC) category under Integrated Circuits. It functions specifically as a DC-DC Switching Controller IC. The product line focuses on efficient voltage regulation solutions for modern electronic systems.
Replacement Considerations
Public confirmed substitute part numbers are not available in the provided source material. Consult official ABLIC documentation for potential cross-references or newer revisions.
