SDE5-D10-FP-Q6E-P-M8

Pressure Sensors Transducers Overview

The Festo SDE5-D10-FP-Q6E-P-M8 is a relative pressure sensor from the SDE5 series, designed for industrial pneumatic applications. It features an M8 plug connector and push-in connection thread. The device operates within a pressure range of 0 to 10 bar, with a maximum setting pressure of 25 bar. It provides one normally open (NO) and one normally closed (NC) switching output via PnP technology. An analog output of 4-20 mA is available for continuous monitoring. The unit has a compact form factor measuring 16mm in width, 41.5mm in depth, and 24.5mm in height. It supports direct insertion installation and functions at temperatures up to 50°C.

Pressure Sensors Transducers Feature Summary

• Integrated PnP switching outputs combined with 4-20 mA analog signal transmission
• Compact design utilizing M8 plug interface and push-in pneumatic connections
• Direct insertion mounting capability for streamlined system integration

Pressure Sensors Transducers Applications

• Monitoring compressed air pressure in automated manufacturing lines
• Vacuum level detection in handling and gripping systems
• Process control in pneumatic actuator feedback loops

Pressure Sensors Transducers Procurement Notes

Verify the specific ordering suffix against official Festo documentation to ensure correct configuration. Confirm that the M8 plug variant matches your existing cabling infrastructure. Check for updated certification marks such as RCM or UL us on the current production batch. Ensure the push-in thread standard aligns with your manifold requirements. Cross-reference the part number with the latest datasheet to avoid obsolete specifications.

Pressure Sensors Transducers Selection Notes

Select this model when both discrete switching logic and continuous analog monitoring are required simultaneously. The PnP output simplifies wiring compared to traditional relay-based sensors. The M8 plug offers a secure electrical connection suitable for dynamic environments. Consider the 4-20 mA range if precise pressure trending is necessary for process optimization. Evaluate the 16mm width for space-constrained panel installations.

Pressure Sensors Transducers Part Context

This component belongs to the Festo SDE5 series, which focuses on versatile pressure and vacuum sensing solutions. The series emphasizes ease of use and superior quality for various industrial automation tasks. The SDE5 line typically includes variants with different connectors and output types to suit diverse application needs.

Pressure Sensors Transducers Replacement Considerations

SDE5-D10-O-Q6E-P-M8

Pressure Sensors Transducers FAQ

What type of pneumatic connection does this sensor utilize?

It uses a push-in connection thread for quick and tool-free tubing attachment.

Does this model support both digital and analog signals?

Yes, it provides PnP switching outputs alongside a 4-20 mA analog output.
