SG-615PT-28.3220MC2

Oscillators Overview

The SG-615PT-28.3220MC2 is a surface-mount crystal oscillator manufactured by Epson Toyocom Corporation. It operates at a fundamental frequency of 28.322 MHz with CMOS and TTL output logic levels. The device requires a 5V supply voltage and offers a frequency stability of ±100 ppm. It features an enable/disable function for power management. The component utilizes a standard SMD package measuring 14.00mm in length and 8.65mm in width, designed for automated assembly processes.

Oscillators Feature Summary

• Provides stable clock signals with CMOS and TTL compatible output waveforms
• Includes enable and disable functionality to control power consumption
• Designed for surface-mount technology integration

Oscillators Applications

• Digital signal processing systems requiring precise timing references
• Communication equipment utilizing standard serial interfaces
• Embedded controller boards needing reliable clock sources

Oscillators Procurement Notes

Verify the specific ordering suffixes against official Epson documentation to ensure correct frequency tolerance and operating temperature range specifications. Confirm that the requested variant matches the required 5V supply voltage and CMOS/TTL output characteristics. Check for RoHS compliance status as indicated in the manufacturer's latest datasheet revisions before finalizing procurement orders.

Oscillators Selection Notes

Select this component when a fixed 28.322 MHz frequency is required for digital circuits. Ensure the design accommodates the 5V supply rail and physical footprint dimensions of 14.00mm x 8.65mm. Consider the ±100 ppm stability requirement against system timing constraints. Verify compatibility with existing PCB layout guidelines for surface-mount oscillators.

Oscillators Part Context

This part belongs to the SG-615 series of surface-mount crystal oscillators from Epson Toyocom. The series provides various frequency options within a standardized package format. The SG-615PT designation indicates specific performance characteristics tailored for general-purpose digital applications requiring reliable clock generation without external tuning components.

Oscillators Replacement Considerations

Consult official cross-reference lists for direct substitutes. Verify pinout compatibility and electrical parameters such as supply voltage and output logic levels before substitution. Ensure thermal and mechanical specifications match the original design requirements.
