SG5032VAN 100.000000M-KJGA0

Oscillators Overview

The SG5032VAN 100.000000M-KJGA0 is a standard clock oscillator manufactured by Epson Timing, operating at a frequency of 100 MHz with an output format of LVDS. It supports supply voltages ranging from 2.5 V to 3.3 V and features a frequency stability of ±50 PPM. The device operates within a temperature range of -40°C to +85°C and utilizes a 6-SMD, no-lead package measuring 5 mm x 3.2 mm.

Oscillators Feature Summary

• Provides LVDS output signals for high-speed digital interfaces.
• Includes enable and disable functionality for power management.
• Utilizes a compact surface-mount package suitable for space-constrained designs.

Oscillators Applications

• High-speed data communication systems
• Network infrastructure equipment
• Consumer electronics requiring precise timing

Oscillators Procurement Notes

Verify the specific suffix KJGA0 against official Epson documentation to confirm packaging quantity and tape-and-reel specifications. Ensure compatibility with system voltage levels and thermal requirements before integration. Cross-reference part numbers with authorized distributors to avoid counterfeit components.

Oscillators Selection Notes

Select this component when LVDS outputs are required for noise immunity in high-frequency applications. Consider the ±50 PPM stability requirement relative to system jitter tolerance. Evaluate the 2.5V to 3.3V supply range against available board power rails.

Oscillators Part Context

This model belongs to the SG5032VAN series of standard oscillators from Epson Timing. The series offers various frequencies and stability options within a standardized 5mm x 3.2mm footprint, designed for reliable performance in industrial and commercial environments.

Oscillators Replacement Considerations

Check for SG5032VAN 100.000000M-KEGA3 as a potential variant with similar electrical characteristics but different packaging or stability ratings. Verify pinout and electrical parameters before substitution.
