SI5395J-A-GM

Clock Generators, PLLs, Frequency Synthesizers Overview

The Skyworks SI5395J-A-GM is a single PLL jitter attenuator and clock multiplier featuring an integrated reference. It provides 12 outputs with frequencies up to 1028 MHz using integer and fractional synthesis modes. The device supports differential inputs from 8 kHz to 750 MHz and LVCMOS inputs from 8 kHz to 250 MHz. Output formats include CML, HCSL, LVCMOS, LVDS, and LVPECL. Operating voltage ranges from 1.71 V to 3.47 V, with a typical current of 150 mA. It functions within a temperature range of -40°C to +85°C and is housed in a 64-LGA package.

Clock Generators, PLLs, Frequency Synthesizers Feature Summary

• Integrates a fourth-generation DSPLL and Multi-Synth technology for ultra-low jitter performance.
• Includes an internal crystal reference to reduce board space and acoustic emissions noise.
• Supports enhanced hitless switching to minimize phase transients during input clock changes.
• Features programmable non-volatile memory for known power-up frequency configurations.

Clock Generators, PLLs, Frequency Synthesizers Applications

• 56G/112G PAM4 SerDes clocking
• OTN muxponders and transponders
• 10/40/100/200/400G networking line cards
• Medical imaging systems

Clock Generators, PLLs, Frequency Synthesizers Procurement Notes

Verify the specific ordering suffix against the manufacturer's latest documentation to ensure correct configuration. Confirm that the integrated reference variant matches the design requirements, as external references are not compatible with this grade. Check for RoHS compliance status and humidity sensitivity handling procedures during storage and assembly.

Clock Generators, PLLs, Frequency Synthesizers Selection Notes

Select this component when board space savings from an integrated reference are prioritized over external crystal flexibility. Ensure the application requires 12 output clocks and supports the specified voltage and temperature ranges. Verify compatibility with ClockBuilder Pro software for configuration. Consider the fixed loop bandwidth characteristics inherent to this grade compared to other variants.

Clock Generators, PLLs, Frequency Synthesizers Part Context

This part belongs to the Si5395 family, which combines fourth-generation DSPLL and Multi-Synth technologies. The J-grade specifically denotes the inclusion of an integrated reference oscillator, distinguishing it from A/B/C/D/P grades that require external crystals. It serves as a high-performance solution for applications demanding low jitter and high integration levels.

Clock Generators, PLLs, Frequency Synthesizers Replacement Considerations

The Si5395A-A-GM is a drop-in compatible alternative but requires an external crystal reference instead of the integrated one. Other Si5395 variants with different output counts or frequency ranges may not be functionally equivalent. Verify pinout and package dimensions remain identical before substitution.
