SVM1045VA_R2_00001

$0.82

Description：DIODE SCHOTTKY 45V 10A TO277A
Series：-
Mfr：Panjit International Inc.
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:a9f265b230f9 Category: Single Diodes Brand: Panjit International Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

SVM1045VA_R2_00001 is listed in the Single Diodes range at ChipApex. The manufacturer field lists Panjit International Inc.. Its product description is DIODE SCHOTTKY 45V 10A TO277A. Review the specifications below when checking this part for your BOM.

Single Diodes specifications for SVM1045VA_R2_00001

Description：DIODE SCHOTTKY 45V 10A TO277A
Series：-
Mfr：Panjit International Inc.
Package：Tape & Reel (TR),Cut Tape (CT)
Technology：Schottky
Voltage - DC Reverse (Vr) (Max)：45 V
Current - Average Rectified (Io)：10A
Voltage - Forward (Vf) (Max) @ If：470 mV @ 10 A
Speed：Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr)：-
Current - Reverse Leakage @ Vr：250 µA @ 45 V
Capacitance @ Vr, F：-
Mounting Type：Surface Mount
Package / Case：TO-277, 3-PowerDFN
Supplier Device Package：TO-277A
Operating Temperature - Junction：-55°C ~ 150°C
Grade：-
Qualification：-

Single Diodes datasheet and documents for SVM1045VA_R2_00001

SVM1045VA_R2_00001

Single Diodes Overview

The SVM1045VA_R2_00001 is a silicon Schottky rectifier manufactured by Panjit International Inc. It features a single-element configuration housed in a TO-277 surface-mount package. The device supports a maximum repetitive peak reverse voltage of 45 V and a continuous forward current of 10 A. Key electrical characteristics include a maximum non-repetitive peak forward surge current of 275 A and a maximum forward voltage of 0.47 V. It operates within a junction temperature range of -55 °C to 150 °C.

Single Diodes Feature Summary

Utilizes Schottky barrier technology for low power loss and high efficiency operation
Features an ultra-low forward voltage drop characteristic
Designed with a cathode-connected case for thermal management

Single Diodes Applications

High-frequency rectification in DC-DC converters
Power supply freewheeling diodes
Reverse polarity protection circuits

Single Diodes Procurement Notes

Verify the specific suffix against official Panjit documentation to confirm exact packaging and reel specifications. Confirm RoHS compliance status through the manufacturer's latest product compliance reports. Ensure the ordering part number matches the required tape-and-reel or cut-tape format for automated assembly processes.

Single Diodes Selection Notes

Select this component for applications requiring efficient rectification at 45 V with 10 A capacity. The TO-277 package offers a compact footprint suitable for space-constrained designs. Consider the low forward voltage for improved thermal performance in high-current scenarios compared to standard PN junction rectifiers.

Single Diodes Part Context

This component belongs to the SVM-100 series of Schottky diodes from Panjit. It is designed as a surface-mount alternative to through-hole rectifiers, providing similar electrical ratings in a smaller form factor. The series targets modern electronics requiring high reliability and reduced power consumption in power conversion stages.
