SX2M11.2896B20F30TNF

Oscillators Overview

The SX2M11.2896B20F30TNF is a 40MHz active crystal oscillator manufactured by Shenzhen SCTF Electronics. It features CMOS output mode and operates at a supply voltage of 3.3V with a typical working current of 20mA. The device provides a nominal frequency of 40MHz with an initial frequency tolerance of ±20ppm and a total frequency stability of ±30ppm over the operating temperature range of -40°C to +85°C.

Oscillators Feature Summary

• CMOS output interface for digital logic compatibility
• Integrated enable/disable control functionality
• Standard surface-mount package design

Oscillators Applications

• General-purpose clock signal generation
• Digital system timing references
• Embedded controller clock sources

Oscillators Procurement Notes

Verify the specific part number suffix against official manufacturer documentation to confirm exact electrical parameters and pinout configuration. Ensure that the requested variant matches the required frequency, tolerance, and package specifications for your application circuit design before finalizing procurement orders.

Oscillators Selection Notes

Select this component based on its 40MHz frequency requirement and CMOS output compatibility. Consider the ±30ppm frequency stability and -40°C to +85°C operating temperature range to ensure suitability for the intended environmental conditions and precision requirements of the target electronic system.

Oscillators Part Context

This model belongs to the series of standard active crystal oscillators produced by Shenzhen SCTF Electronics. These components are designed to provide stable clock signals for various electronic applications requiring precise timing references within standard industrial temperature ranges.

Oscillators Replacement Considerations

Public confirmed substitute part numbers are not available in the provided source material.
