SXOB36.000A20F30TNN

Oscillators Overview

The SXOB36.000A20F30TNN is a 36 MHz crystal oscillator manufactured by Shenzhen SCTF Electronics. It operates with CMOS output levels and features a 5V enable/disable control function. The component utilizes an 8-DIP package, specifically configured as a half-size metal can with four leads. This configuration supports standard clock signal generation for electronic circuits requiring precise frequency stability.

Oscillators Feature Summary

• CMOS output signal compatibility
• Integrated 5V enable and disable control functionality
• Half-size metal can DIP packaging

Oscillators Applications

• General-purpose clock signal generation in digital circuits
• Embedded systems requiring stable timing references
• Electronic equipment utilizing standard CMOS interfaces

Oscillators Procurement Notes

Verify the specific package dimensions against the mechanical drawing to ensure fit within the target enclosure. Confirm that the 5V logic level matches the system voltage requirements. Ensure the enable pin is properly managed in the design to prevent unintended operation or excessive power consumption when the device is not active.

Oscillators Selection Notes

Select this component when a 36 MHz frequency is required alongside CMOS output compatibility. The enable feature allows for power management integration. Consider the physical size constraints of the half-size metal can package during layout planning. Validate thermal performance if the operating environment exceeds standard commercial ranges.

Oscillators Part Context

This part belongs to the series of surface mount and through-hole oscillators designed for general electronics applications. It provides a fixed frequency output without requiring external tuning components. The metal can construction offers shielding against electromagnetic interference compared to plastic packages.

Oscillators Replacement Considerations

Direct substitutes must match the 36 MHz frequency, CMOS output type, and 5V enable capability. Verify pinout compatibility before replacement. Alternative packages may require adapter solutions if space permits.
