TA-8.192MBD-T

Oscillators Overview

The TA-8.192MBD-T is a MEMS oscillator manufactured by TXC Corporation, operating at a nominal frequency of 8.192 MHz. It utilizes CMOS output and functions as a standard XO type device. The component supports a supply voltage range of 2.5V to 3.3V with a maximum supply current of 25mA. Frequency stability is rated at ±25ppm across an operating temperature range of -40°C to +85°C. It features an enable/disable function and is housed in a compact 4-SMD, No Lead package measuring 2.50mm x 2.00mm x 0.80mm.

Oscillators Feature Summary

• MEMS technology provides high reliability and stable clock signals
• Integrated enable/disable functionality for power management
• CMOS output compatible with digital logic interfaces
• Compact surface-mount design suitable for space-constrained applications

Oscillators Applications

• Desktop computers and notebook systems
• Computer peripherals and interface cards
• Network communication equipment
• Consumer electronics requiring precise timing

Oscillators Procurement Notes

Verify the specific ordering suffix and voltage rating carefully, as variations exist within the TA series. Confirm that the required supply voltage matches your system design, as some variants support different voltage levels. Check for end-of-life status or alternative recommendations from the manufacturer due to potential discontinuation. Ensure the package dimensions align with your PCB footprint requirements before finalizing procurement.

Oscillators Selection Notes

Select this component when a small form factor MEMS oscillator is required for digital systems. Consider the ±25ppm stability requirement against your system's jitter tolerance. Verify that the CMOS output level matches your load requirements. Evaluate the enable/disable feature necessity for power-sensitive designs. Compare physical dimensions against available board space constraints.

Oscillators Part Context

This part belongs to the TA series of silicon MEMS oscillators from TXC Corporation. These devices are designed to replace traditional quartz crystals and resonators in modern electronic applications. The series offers improved shock resistance and lower power consumption compared to piezoelectric alternatives. They are commonly used in computing and telecommunications infrastructure.

Oscillators Replacement Considerations

Public confirmed substitute part numbers include TD-8.192MBD-T and TB-8.192MBE-T. Note that these substitutes may differ in package size or frequency stability specifications. Verify electrical compatibility and mechanical fit before substitution. Consult official datasheets for detailed parameter comparisons.
