TSM035NB04LCZ C0G

$2.00

Description：40V, 157A, SINGLE N-CHANNEL POWE
Series：-
Mfr：Taiwan Semiconductor Corporation
Package：Tube

SKU:02a4309514a2 Category: Single FETs, MOSFETs Brand: Taiwan Semiconductor Corporation

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

TSM035NB04LCZ C0G is listed in the Single FETs, MOSFETs range at ChipApex. The manufacturer field lists Taiwan Semiconductor Corporation. Its product description is 40V, 157A, SINGLE N-CHANNEL POWE. Review the specifications below when checking this part for your BOM.

Single FETs, MOSFETs specifications for TSM035NB04LCZ C0G

Description：40V, 157A, SINGLE N-CHANNEL POWE
Series：-
Mfr：Taiwan Semiconductor Corporation
Package：Tube
FET Type：N-Channel
Technology：MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)：40 V
Current - Continuous Drain (Id) @ 25°C：18A (Ta), 157A (Tc)
Drive Voltage (Max Rds On, Min Rds On)：4.5V, 10V
Rds On (Max) @ Id, Vgs：3.5mOhm @ 18A, 10V
Vgs(th) (Max) @ Id：2.5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs：111 nC @ 10 V
Vgs (Max)：±20V
Input Capacitance (Ciss) (Max) @ Vds：6350 pF @ 20 V
FET Feature：-
Power Dissipation (Max)：2W (Ta), 156W (Tc)
Operating Temperature：-55°C ~ 150°C (TJ)
Grade：-
Qualification：-
Mounting Type：Through Hole
Supplier Device Package：TO-220
Package / Case：TO-220-3

Single FETs, MOSFETs datasheet and documents for TSM035NB04LCZ C0G

TSM035NB04LCZ C0G

Single FETs, MOSFETs Overview

The TSM035NB04LCZ C0G is a single N-channel power MOSFET manufactured by Taiwan Semiconductor. It features a 40V drain-source voltage rating and a maximum on-state resistance of 3.5mΩ at VGS=10V. The device supports a continuous drain current of 157A at TC=25°C and a pulsed drain current of 628A. Total gate charge is typically 110nC. It utilizes a TO-220 package with a junction-to-case thermal resistance of 0.8°C/W. The component is logic level compatible, halogen-free, and RoHS compliant.

Single FETs, MOSFETs Feature Summary

Logic level gate drive capability for efficient switching control
Low on-state resistance to minimize conductive losses
Low gate charge optimized for fast power switching applications
100% tested for Unclamped Inductive Switching (UIS) and gate resistance

Single FETs, MOSFETs Applications

BLDC Motor Control
Battery Power Management
DC-DC Converter

Single FETs, MOSFETs Procurement Notes

Verify the specific ordering code suffix against the manufacturer's official documentation to confirm packaging details. Confirm that the TO-220 tube packing matches project requirements. Ensure compliance with RoHS standards and halogen-free specifications as defined in the datasheet before finalizing procurement orders.

Single FETs, MOSFETs Selection Notes

Select this component for high-current switching applications requiring low conduction losses. Evaluate the thermal management strategy based on the specified junction-to-case thermal resistance. Consider the logic level gate threshold when designing the driver circuitry to ensure reliable turn-on across the operating temperature range.

Single FETs, MOSFETs Part Context

This part belongs to the TSM035NB04LCZ series of N-channel power MOSFETs from Taiwan Semiconductor. It is designed for general-purpose power switching where efficiency and thermal performance are critical. The device integrates standard silicon technology within a robust TO-220 package suitable for through-hole mounting.

Single FETs, MOSFETs Replacement Considerations

Consult the manufacturer's official cross-reference data for verified substitutes. Ensure any replacement maintains equivalent voltage ratings, current capabilities, and package dimensions.
