TSMV-H50HM33ST2C-28.224M-TR

$3.15

Description：XTAL OSC VCXO 28.2240MHZ HCMOS
Series：TSMV
Mfr：Transko Electronics, Inc.
Package：Tape & Reel (TR)

SKU:45822dc4556d Category: Oscillators Brand: Transko Electronics, Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

TSMV-H50HM33ST2C-28.224M-TR is listed in the Oscillators range at ChipApex. The manufacturer field lists Transko Electronics, Inc.. Its product description is XTAL OSC VCXO 28.2240MHZ HCMOS. Review the specifications below when checking this part for your BOM.

Oscillators specifications for TSMV-H50HM33ST2C-28.224M-TR

Description：XTAL OSC VCXO 28.2240MHZ HCMOS
Series：TSMV
Mfr：Transko Electronics, Inc.
Package：Tape & Reel (TR)
Base Resonator：Crystal
Type：VCXO
Frequency：28.224 MHz
Function：Enable/Disable
Output：HCMOS
Voltage - Supply：3.3V
Frequency Stability：±50ppm
Absolute Pull Range (APR)：±100ppm
Operating Temperature：0°C ~ 70°C
Spread Spectrum Bandwidth：-
Current - Supply (Max)：50mA
Ratings：-
Mounting Type：Surface Mount
Package / Case：6-SMD, No Lead
Size / Dimension：0.276" L x 0.197" W (7.00mm x 5.00mm)
Height - Seated (Max)：0.071" (1.80mm)
Supplier Device Package：-
