TSMV-H50HM33ST2E-27.000M-TR

Oscillators Overview

The TSMV-H50HM33ST2E-27.000M-TR is a Voltage Controlled Crystal Oscillator (VCXO) manufactured by Transko Electronics, Inc. It operates at a nominal frequency of 27.0000 MHz and utilizes HCMOS output logic levels. The device is designed for operation with a supply voltage of 3.3V and features an enable/disable control function. It is housed in a 6-SMD, No Lead package with dimensions of 7.0 x 5.0 x 2.0 mm. The component supports an operating temperature range of 0℃ to +70℃ and draws a current of 50mA.

Oscillators Feature Summary

• Voltage controlled crystal oscillator architecture providing frequency tunability
• HCMOS output interface compatible with standard digital logic circuits
• Integrated enable and disable functionality for power management
• RoHS compliant lead-free construction suitable for modern assembly processes

Oscillators Applications

• Clock generation systems requiring precise frequency stability
• Telecommunications equipment utilizing 27 MHz reference signals
• Digital signal processing applications needing low phase noise sources
• Embedded systems requiring programmable clock frequencies

Oscillators Procurement Notes

Verify the specific ordering suffix against the manufacturer's official datasheet to ensure compatibility with required frequency tolerance and load capacitance specifications. Confirm that the 6-SMD package variant matches the PCB footprint design constraints. Ensure the HCMOS output level aligns with the receiving circuit's input voltage thresholds before finalizing procurement orders.

Oscillators Selection Notes

Select this component when a fixed 27 MHz reference with voltage-controlled tuning capability is required. The 3.3V supply requirement dictates compatibility with low-voltage digital systems. The HCMOS output ensures direct interfacing without additional buffering in many standard logic families. Consider the 0℃ to +70℃ industrial temperature range for environmental suitability.

Oscillators Part Context

This part belongs to the TSMV series of VCXOs from Transko Electronics, Inc., which offers various frequency options within the same physical package form factor. The series provides standardized solutions for clock generation needs across different communication protocols. The specific model denotes the 27 MHz frequency variant within this broader product family.

Oscillators Replacement Considerations

Direct substitutes include other Transko TSMV series parts with identical package dimensions but different frequency ratings, such as the TSMV-H50HM33ST2C-28.224M-TR, provided the system design accommodates the alternative frequency value.
