TSP-H50CQ33ST-8.000M-TR

Oscillators Overview

The TSP-H50CQ33ST-8.000M-TR is an active crystal oscillator manufactured by Transko Electronics, Inc. It operates at a nominal frequency of 8.000 MHz with HCMOS output logic levels. The device is powered by a single 3.3V supply and features enable/disable functionality for power management. It is housed in a compact 4-SOJ package with a 5.08mm pitch, designed for surface-mount applications. This standard XO provides reliable clock signals for digital circuits requiring precise timing synchronization.

Oscillators Feature Summary

• HCMOS output interface for standard digital logic compatibility
• Integrated enable and disable control pin for power optimization
• Surface-mount SOJ package design for automated assembly

Oscillators Applications

• Avionics systems requiring precise timing synchronization
• Navigation system clock generation
• Radar system signal processing
• Communication equipment timing references

Oscillators Procurement Notes

Verify the specific ordering suffix to ensure the correct voltage and package configuration matches your design requirements. Confirm that the HCMOS output level aligns with your downstream logic inputs. Check the enable/disable pin configuration against your power management scheme. Ensure the 3.3V supply rail is stable within specified limits. Validate the 8.000 MHz frequency tolerance against your system's timing budget before finalizing procurement.

Oscillators Selection Notes

Select this component when a 3.3V HCMOS oscillator is required in a small form factor. The enable feature supports dynamic power management strategies. Consider the 4-SOJ package dimensions for PCB layout constraints. Verify that the operating temperature range meets your environmental specifications. Ensure the load capacitance requirements are compatible with your circuit design.

Oscillators Part Context

This part belongs to the TSP series of crystal oscillators from Transko Electronics. The series offers various frequencies and packages to suit different application needs. The TSP-H50CQ33ST variant specifically targets 3.3V applications with HCMOS outputs. It is designed for high-reliability environments where stable clock signals are critical. The series is known for consistent performance across industrial and commercial temperature ranges.

Oscillators Replacement Considerations

Direct substitutes may include other 8MHz HCMOS oscillators in similar packages from Transko or competitors. Verify electrical parameters such as supply voltage, output type, and current consumption. Check mechanical dimensions and pinout compatibility for board-level replacement. Ensure frequency stability and phase noise specifications meet original design requirements.
